NETGEAR GS308EP Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

8-Port Gigabit Ethernet PoE+ Plus Switch (62W)

Description

300 Series SOHO Plus (GS308EP)

The NETGEAR 8-Port Gigabit Ethernet PoE+ Plus Switch delivers essential business networking features and powers PoE+ devices like VoIP phones, IP cameras, and more.

Gigabit Ethernet
8 ports provide up to 1000 Mbps of dedicated, non-blocking bandwidth each.

PoE+ Support
8 PoE+ ports provide a total of 62W of power so you can power and connect your devices with a single wire.

Advanced PoE Controls
Manage PoE prioritization, PoE power limit per port, and more for simple control over all PoE-powered devices.

Non-Blocking Switching
10Gbps (10/100/1000 Mbps) line rate fabric ensures congestion-free connectivity to your devices.

Fanless Design
Silent operation makes this switch perfect for noise-sensitive environments.

Versatile Mounting Options
Install your switch on your desktop, or mount it to your wall or rack with the hardware provided in the box.

Specifications

Management features
Multicast support	Yes
Switch type	Managed
Web-based management	Yes
Quality of Service (QoS) support	Yes
MIB support	Yes
Switch layer	L2/L3
Network
IGMP snooping	Yes
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Full duplex	Yes
VLAN support	Yes
Port mirroring	Yes
Link aggregation	Yes
Flow control support	Yes
Ethernet LAN data rates	1000 Mbit/s
Broadcast storm control	Yes
10G support	No
Virtual LAN features
VLAN support	Yes
Technical details
Product colour	Black
Rack mounting	No
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Data transmission
Jumbo frames	9216
MAC address table	4000 entries
Switching capacity	16 Gbit/s
Jumbo frames support	Yes
Security
Loop protection	Yes
IGMP snooping	Yes
DHCP features	DHCP client
Multicast features
Multicast support	Yes
Certificates
Certification	CE mark, commercial, FCC Part 15 class B, CE/EN55032/24, VCCI, ACMA, CSA safety, KC, BSMI
Design
Product colour	Black
LED indicators	Yes
Certification	CE mark, commercial, FCC Part 15 class B, CE/EN55032/24, VCCI, ACMA, CSA safety, KC, BSMI
Rack mounting	No
Performance
Harmonized System (HS) code	85176990
Indication
LED indicators	Yes
Power
Power supply included	Yes
Input current	2.4 A
DC input voltage	54 V
Power source	DC
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity	8
Power over Ethernet (PoE) ports quantity	8
Power over Ethernet (PoE)	Yes
Operational conditions
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	0 - 95%
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90%
Operating altitude	0 - 3000 m
Weight & dimensions
Width	158 mm
Depth	101 mm
Height	27 mm
Weight	490 g
Packaging data
Quick start guide	Yes
Manual	Yes
Cables included	DC
Logistics data
Harmonized System (HS) code	85176990
Other features
Ethernet LAN data rates	1000 Mbit/s
Packaging content
Quick start guide	Yes
Manual	Yes
Cables included	DC
