Netgear

NETGEAR GS316EP Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

SKU GS316EP-100UKS
£223.59
£178.07
£223.59
£178.07
Excluding taxes
16-Port PoE+ Gigabit Ethernet Plus Switch (180W) with 1 SFP Port

Description

16PT GE Plus Switch W/ POE+

16-Port PoE+ Gigabit Ethernet Plus Switch (180W) with 1 SFP Port

The NETGEAR 16-Port PoE+ Gigabit Ethernet Plus Switch delivers essential business networking features and powers PoE+ devices like VoIP phones IP cameras and more.

Features

Gigabit Ethernet
16 ports provide up to 1000 Mbps of dedicated non-blocking bandwidth each

PoE+ Support
15 PoE+ ports provide a total of 180W of power so you can power and connect your devices with a single wire

Advanced PoE Controls
Manage PoE prioritization PoE power limit per port PoE scheduling and more for simple control over all PoE-powered devices

Non-Blocking Switching
10Gbps (10/100/1000 Mbps) line rate fabric ensures congestion-free connectivity to your devices

Fanless Design
Silent operation makes this switch perfect for noise-sensitive environments

Versatile Mounting Options
Install your switch on your desktop or mount it to your wall with the hardware provided in the box

Specifications

Management features
Multicast support Yes
Switch type Managed
Web-based management Yes
Quality of Service (QoS) support Yes
Ports & interfaces
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
SFP module slots quantity 1
Basic switching RJ-45 Ethernet ports quantity 16
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Power connector DC-in jack
Network
IGMP snooping Yes
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
Networking standards IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Full duplex Yes
VLAN support Yes
Rate limiting Yes
Port mirroring Yes
Number of VLANs 64
Link aggregation Yes
Flow control support Yes
Ethernet LAN data rates 10,100,1000 Mbit/s
10G support No
Virtual LAN features Port-based VLAN, Tagged VLAN
Virtual LAN features
VLAN support Yes
Number of VLANs 64
Virtual LAN features Port-based VLAN, Tagged VLAN
Data transmission
Number of multicast groups filtered 128
Number of VLANs 64
Jumbo frames 10000
Packet buffer memory 0.192 MB
MAC address table 4096 entries
Switching capacity 32 Gbit/s
Store-and-forward Yes
Jumbo frames support Yes
Performance
Packet buffer memory 0.192 MB
Mean time between failures (MTBF) 784742 h
Harmonized System (HS) code 85176990
Fanless Yes
Power
Power connector DC-in jack
Technical details
Product colour Black
Mean time between failures (MTBF) 784742 h
Housing material Metal
Rack mounting No
Sustainability compliance Yes
Compliance certificates CE
Security
IGMP snooping Yes
Queue scheduling algorithms Weighted Round Robin (WRR)
Password protection Yes
DHCP features DHCP client
Multicast features
Number of multicast groups filtered 128
Multicast support Yes
Certificates
Certification FCC 15 B CE/EN55032/24 VCCI ACMA CSA KC BSMI
Memory
Packet buffer memory 0.192 MB
Design
Wall mountable Yes
Product colour Black
LED indicators Yes
Housing material Metal
Certification FCC 15 B CE/EN55032/24 VCCI ACMA CSA KC BSMI
Rack mounting No
Indication
LED indicators Yes
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity 15
Total Power over Ethernet (PoE) budget 180 W
Power over Ethernet (PoE) Yes
Operational conditions
Storage temperature (T-T) -20 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Operating altitude 0 - 3000 m
Weight & dimensions
Width 286 mm
Depth 102 mm
Height 27 mm
Weight 880 g
Packaging data
User guide Yes
Cables included AC
Sustainability
Sustainability compliance Yes
Logistics data
Harmonized System (HS) code 85176990
Other features
Ethernet LAN data rates 10,100,1000 Mbit/s
Packaging content
User guide Yes
Cables included AC
