NETGEAR Insight Cloud Managed WiFi 6 AX3600 Dual Band Access Point (WAX620) 3600 Mbit/s White Power over Ethernet (PoE)

3.6 Gb/s, 2.4/5 GHz, 2.5G LAN, IEEE 802.11ax, 12 VDC, 2.5A, 205.7x205.7x34.3 mm

Description

Get powerful and reliable WiFi 6 connectivity for all your devices, even in high-density environments. Simplified enterprise-grade security and networking for the smaller business.

High-Performance Business WiFi
Faster and more reliable dual band WiFi 6 with 8 streams and up to 2.4Gbps in 5GHz band and 1.2Gbps in 2.4GHz band

Ideal for High Density Environments
Ultimate WiFi performance for schools, hotels, restaurants, and conference centers.

Greater Network Capacity
Enjoy 4x more connection capacity than your current WiFi and improved efficiency for longer battery life.

Seamless Wireless Mesh
Wire-free installation with other WAX620, WAX610, WAX610Y, WAC540, or WAC564 creates the perfect seamless business network.

Multi-Gigabit Speed
Includes a 2.5 Gbps Ethernet port with PoE for high speed wired network connectivity and easy wiring

Easy Setup
Set up, configure, and manage with NETGEAR Insight

Flexible Mounting
Easy to securely install on the wall of a suspended ceiling with the hardware included

Business-Level Security
WPA3 for the highest level of WiFi connection security

8 Wireless Networks (SSIDs)
Separate and secure networks for admin, guests, employees and IoT devices like cameras, locks and more

Separate VLANs
Keep admin, employee, visitor, HR, Finance department networks safely separated from each other

Specifications

Data transmission
Ethernet LAN data rates	100,1000,2500 Mbit/s
Maximum data transfer rate	3600 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Auto Wireless Distribution System (WDS)	Yes
Auto MDI/MDI-X	Yes
Web-based management	Yes
VLAN support	Yes
Networking standards	IEEE 802.11ax, IEEE 802.11i, IEEE 802.3af, IEEE 802.3at
Modulation	OFDM
Ethernet LAN data rates	100,1000,2500 Mbit/s
Maximum data transfer rate	3600 Mbit/s
MIMO type	Multi User MIMO
MIMO	Yes
Wireless LAN features
Modulation	OFDM
Network
Networking standards	IEEE 802.11ax, IEEE 802.11i, IEEE 802.3af, IEEE 802.3at
Management features
VLAN support	Yes
Web-based management	Yes
Features
2.4 GHz	Yes
5 GHz	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Auto MDI/MDI-X	Yes
VLAN support	Yes
Networking standards	IEEE 802.11ax, IEEE 802.11i, IEEE 802.3af, IEEE 802.3at
Modulation	OFDM
Ethernet LAN data rates	100,1000,2500 Mbit/s
Maximum data transfer rate	3600 Mbit/s
MIMO type	Multi User MIMO
MIMO	Yes
Maximum data transfer rate (2.4 GHz)	1200 Mbit/s
Maximum data transfer rate (5 GHz)	2400 Mbit/s
Security
Auto Wireless Distribution System (WDS)	Yes
Security algorithms	EAP-TLS, PEAP, SSL/TLS, TTLS, WPA, WPA2, WPA3
MAC address filtering	Yes
Ports & interfaces
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes
Power
Output voltage	12 V
Output current	2.5 A
Power over Ethernet (PoE)	Yes
Design
Placement	Ceiling, Wall
Product colour	White
LED indicators	LAN, Power, WLAN
Antenna
Antenna type	Internal
Antenna gain level (max)	4.3 dBi
Technical details
Harmonized System (HS) code	85176990
Indication
LED indicators	LAN, Power, WLAN
Weight & dimensions
Width	205.7 mm
Depth	205.7 mm
Weight	783 g
Height	34.3 mm
Packaging data
Quick start guide	Yes
Mounting kit	Yes
Packaging content
Quick start guide	Yes
Mounting kit	Yes
Quantity per pack	1 pc(s)
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Logistics data
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
