ASUS TUF Gaming 850W Gold power supply unit 24-pin ATX ATX Black

850 watt, fully modular power supply, ATX 3.0 compatible, Axial-tech fan, PCB coating, double ball bearings

Key Features

• Capacitors and chokes pass demanding tests to achieve Military-grade Certification
• Dual ball fan bearings can last up to twice as long as sleeve bearing designs
• A protective PCB coating protects against moisture, dust, and extreme temperatures
• An 80 Plus Gold Certification is the result of Japanese capacitors and other premium components
• Axial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure
• Fully modular etched cables keep your rig neat and tidy

Description

The TUF Gaming 850W Gold is an efficient, resilient and dependable PSU that’s engineered for the long haul.

Built For The Long Haul
The ASUS TUF Gaming 850W Gold packs military-grade strength, a flagship fan design, and PCB protection for efficient, durable power delivery. The result is a PSU that will reliably fuel your rig for years to come.

TUF Components
Top marks
With military-grade components, including capacitors rated for 105°C operation and up to 170,000 hours’ lifespan, the ASUS TUF Gaming 850W Gold empowers you to build in confidence.​

80 Plus Gold Certification
Heart of gold
The TUF Gaming 850W Gold Aura Edition features efficient, low-ESR Japanese capacitors to ensure efficient operation — affording it 80 PLUS® Gold status. This means it delivers up to 92% efficiency, resulting in less heat, reduced fan noise, and increased reliability.​

10-year Warranty
A decade of power​
We're so confident about the reliability of the TUF Gaming 850W Gold that we back it with a 10-year worldwide warranty.​

Specifications

Cooling
Fan diameter	13.5 cm
Number of fans	1 fan(s)
Cooling type	Active
Design
80 PLUS certification	80 PLUS Gold
Product colour	Black
Fan diameter	13.5 cm
Number of fans	1 fan(s)
Cooling type	Active
Power
Total power	850 W
AC input voltage	100 - 240 V
Combined power (+3.3V)	130 W
Combined power (+12V)	850 W
Combined power (+5V)	130 W
Combined power (-12V)	9.6 W
Combined power (+5Vsb)	15 W
Max output current (+3.3V)	25 A
Max output current (+12V)	70.8 A
Max output current (+5V)	25 A
Max output current (-12V)	0.8 A
Max output current (+5Vsb)	3 A
Power protection features	Over current, Over power, Over voltage, Short circuit, Under voltage
Efficiency	92%
Ports & interfaces
Motherboard power cable length	61 cm
SATA power cable length	120,400 mm
Peripheral (Molex) power cable length	150,400 mm
PCI Express power cable length	67.5 cm
CPU power cable length	65 cm
Motherboard power connector	24-pin ATX
Number of SATA power connectors	5
Peripheral (Molex) power connectors (4-pin)	4
PCI Express power connectors (8-pin)	3
CPU power connector (4+4 pin)	Yes
Cabling type	Fully-Modular
PCI Express power connectors (16-pin)	1
Performance
Power supply unit (PSU) form factor	ATX
80 PLUS certification	80 PLUS Gold
Purpose	PC
ATX version	3.1
Certificates
Compliance certificates	RoHS
80 PLUS certification	80 PLUS Gold
Packaging content
Cables included	AC, CPU, PCIe, Peripheral (Molex), SATA
Weight & dimensions
Width	150 mm
Depth	150 mm
Height	86 mm
Weight	2.38 kg
Packaging data
Cables included	AC, CPU, PCIe, Peripheral (Molex), SATA
Package depth	200 mm
Package width	310 mm
Package height	108 mm
Package type	Box
Package weight	3.07 kg
Technical details
Compliance certificates	RoHS
