GIGABYTE GB-BNi3-N305 Black

Intel Core i3 N305, USB-C, LAN, 163.5 x 116.8 x 28.5 mm

Key Features

• Simplified Design, Featherweight Feel
• 12th Gen Intel® Core™ i3 Processor N305
• Intel® UHD Graphics 1250
• Super Fast 2.5G LAN + Wi-Fi 6 Module
• 3 x 4K Module - 2 x HDMI 2.1 and 1 x DP 1.4
• 2 x 2280 M.2 Slots for SSD
• 3 x USB 3.2 Gen2 (2 x Type-A + 1 x Type-C) , 3 x USB 2.0 Ports
• Low Noise
• VESA Support

Description

Experience the merging of real and virtual worlds with our refreshing and impressive design.
The product boasts a sleek and contemporary grid design on its exterior, creating a fresh and minimalist impression. The intricately patterned surface produces a pleasing interplay of light, shadow, reflection, and refraction from different angles, for an overall pleasant aesthetic. This design not only enhances the product's visual appeal, but also symbolizes the numerous possibilities of integrating and merging virtual and real elements within this compact mini-PC.

Intel® Processor and Intel® Core™ i3 N-Series Processors deliver the performance you need at an affordable price to allow you to connect, learn, and play anywhere. The new Intel “Gracemont” CPU microarchitecture built on the latest Intel 7 process features up to 8 efficient cores (“E-cores”), enabling easy, responsive, streamlined experiences. You can scale up to BRIX BNi3 series (Intel® Core™ i3-N305) with an Intel Core i3 N-series platform for a 3.8 GHz turbo frequency and enable Intel® Wi-Fi 6E (Gig+), next-gen Intel® UHD Graphics, enhanced Image Processing Unit (IPU 6) to enjoy a balance of performance and value for the essential BRIX that’s right for you. With the above technologies, users can experience faster browsing and better productivity to accomplish more. Intel N-series processors harness power and efficiency to support learning, streaming and productivity at an affordable cost.

Performance
Intel® Processor and Intel® Core i3 N-Series Processor is much more powerful than the prior generation. The all-new Intel 7nm manufacturing process and E-core (Efficient Core) architecture, users can benefit not only from the performance boost, but also compute with greater power efficiency. Overall, generational performance improvements are easily 30% or more.

USB Type-C Connector
The USB Type-C™ is a new reversible connector that comes with a variety of useful features, including support for USB 3.2 gen2, which provides transfer speeds of up to 10 Gb/s.

Dual M.2 Storage Supports
It can support dual M.2 SSDs (2x2280) based on PCI-e/SATA technology. Users can install two M.2 SSDs for faster boot-up and application loading, as well as a double-capacity HDD for all kinds of media content, files, and documents without any space limitations.

Specifications

Processor
Thermal Design Power (TDP)	15 W
Built-in processor	Yes
Processor boost frequency	3.8 GHz
Processor threads	8
Processor cores	8
Processor family	Intel® Core™ i3
Processor manufacturer	Intel
CPU configuration (max)	1
Processor cache	6 MB
Memory
Memory slots type	SO-DIMM
Number of memory slots	1
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	3200 MHz
Maximum internal memory	32 GB
Video
On-board graphics card	Yes
Graphics card family	Intel
Storage
Supported storage drive types	SSD
Storage drive sizes supported	M.2
Storage drive interface	PCI Express, Serial ATA
SSD form factor	M.2
Graphics
On-board graphics card	Yes
Graphics card family	Intel
On-board graphics card model	Intel® UHD Graphics
Network
Ethernet LAN	Yes
Wi-Fi	Yes
LAN controller	Intel I226-V
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Ports & interfaces
DisplayPort version	1.4
Combo headphone/mic port	Yes
DC-in jack	Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
HDMI version	2.1
DisplayPorts quantity	1
USB 2.0 ports quantity	3
HDMI ports quantity	2
Ethernet LAN (RJ-45) ports	1
Expansion slots
PCI slots	3
Design
VESA mounting	Yes
Product type	Mini PC barebone
Cable lock slot type	Kensington
Cable lock slot	Yes
On/off switch	Yes
Panel mounting interface	75 x 75,100 x 100 mm
Product colour	Black
Performance
Windows operating systems supported	Windows 11
Colour
Product colour	Black
Technical details
Cable lock slot type	Kensington
Cable lock slot	Yes
Panel mounting interface	75 x 75,100 x 100 mm
Processor cores	8
Software
Windows operating systems supported	Windows 11
Management features
On/off switch	Yes
Power
AC input voltage	100 - 240 V
AC adapter output voltage	19 V
AC adapter output current	4.74 A
Power supply	90 W
Operational conditions
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Weight & dimensions
Width	163.5 mm
Depth	116.8 mm
Height	28.5 mm
