TP-LINK

TP-Link 8-Port Gigabit Managed Reverse PoE Switch

SKU RP108GE
£24.44
£24.44
Excluding taxes
Reverse PoE, CSMA/CD, 7 x PoE-in RJ45, 1 x PoE-out RJ45, 10/100/1000Mbps, 11.9 Mbps, 16 Gbps, 158 × 99.1 × 25 mm

Key Features

  • 7 PoE input and 1 PoE output 10/100/1000 Mbps RJ45 Ports
  • 1 DC output port that supports both 5V and 12 V voltage switching
  • Durable metal casing of superior quality and professional appearance
  • Intelligent management via a web user interface and downloadable utility
  • Green technology reduces power consumption

Description

What This Product Does
The Passive PoE switch TL-RP108GE has seven gigabit PoE input ports that allow it to receive power from user outlets via PoE injectors. Equipped with one PoE output port, the switch can supply power to CPEs and similar devices via Port 8. The DC output port supports both 5 V and 12 V optional output voltage and can be used to power devices like ONTs. With data switching and PoE integrated into a single unit, TL-RP108GE saves space, minimizes cabling, and eliminates the need for dedicated electrical outlets—lowering deployment costs and simplifying installation for PoE-capable devices.

Specifications

Management features
Reset button Yes
Switch type Managed
Quality of Service (QoS) support Yes
Switch layer L2
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 8
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity 0
Installed SFP+ modules quantity 0
Network
Networking standards IEEE 802.3ab, IEEE 802.3i, IEEE 802.3p, IEEE 802.3q, IEEE 802.3u, IEEE 802.3x
Full duplex Yes
VLAN support Yes
Rate limiting Yes
Port mirroring Yes
Number of VLANs 4000
Broadcast storm control Yes
10G support No
Half duplex Yes
Virtual LAN features Port-based VLAN, Tagged VLAN
IGMP snooping Yes
Data transmission
Jumbo frames 16000
MAC address table 4000 entries
Switching capacity 16 Gbit/s
Store-and-forward Yes
Jumbo frames support Yes
Static route Yes
Forwarding rate 11.9 Mpps
Number of VLANs 4000
Security
Loop protection Yes
IGMP snooping Yes
Design
Reset button Yes
Product colour Black
LED indicators Yes
Certification FCC, CE, RoHS
Power
Power supply included No
Input voltage 5 V
Input current 1 A
Power source DC
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity 8
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) type supported Passive PoE
Operational conditions
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 5 - 90%
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 10 - 90%
Virtual LAN features
VLAN support Yes
Number of VLANs 4000
Virtual LAN features Port-based VLAN, Tagged VLAN
Weight & dimensions
Width 158 mm
Depth 99.1 mm
Height 25 mm
Technical details
Product colour Black
Performance
Harmonized System (HS) code 85176990
Certificates
Certification FCC, CE, RoHS
Indication
LED indicators Yes
Other features
Input voltage 5 V
Logistics data
Harmonized System (HS) code 85176990
