AOC U3 U32U3CV computer monitor 80 cm (31.5") 3840 x 2160 pixels 4K Ultra HD LCD Black

Screen size (inch) 31.5, Panel resolution 3840x2160, Max Refresh rate 60 Hz, Panel type Nano IPS, USB-C connectivity 1 x USB-C (DP1.4 Alt Mode, USB3.2 Gen 2 - upstream, 10Gbps, w/ HDR, Max. PD 96W Smart Power, HDR, Adaptive Sync), 1 x USB-C (USB3.2 Gen 2 - upstream, 10Gbps), 1 x USB-C (USB3.2 Gen 2 - downstream, 10Gbps, power supply up to 15W), HDMI HDMI 2.0 x 2, Display Port DisplayPort 1.4 x 1, Sync technology (VRR) Adaptive Sync

Reasons To Buy

Graphic Pro

Bigger, brighter, and better monitor to unleash creativity.The AOC U3 Graphic Pro monitors convey stunning and accurate colors, sharp details, and smooth motion to meet the needs of creative professionals who work with high-quality visuals. Setting up, adjusting, and connecting with your devices is also easy.

Red Dot Winner 2023

The AOC U3 Graphic Pro Monitorwon the category of product design. The Red Dot Award is among the most valued international competitions for product design, communication design, and design concepts.

98% DCI-P3

The AOC Graphic Pro line offers 98% DCI-P3, 100% sRGB, and 100% Rec. 709 coverage—perfect for creators demanding true-to-life colors and exceptional accuracy in every project.

Calman Ready

Calman Ready displays and devices are equipped with the ability to communicate directly with Portrait Displays’ Calman® color calibration software. Devices that are Calman Ready can quickly connect with the software and leverage its precise and automated calibration capabilities (AutoCal™).  Calman Ready allows for easy, precise and quick calibrations with your brand-new AOC display.

Delta E<2

Delta E <2 color accuracy means superior, accurate color reproduction, achieving better than the eye can see color difference.

Nano IPS

Nano IPS technology involves nanoparticles which are applied to a LED backlight of an IPS-panel display. These particles absorb excessive light wavelenghts in order to increase color gamut of a display.

USB-C Docking

Simplify the connections with one cable only. The USB-C connection provides DisplayPort Alternate Mode for transferring high-resolution video signals from a notebook to the monitor while simultaneously charging the notebook’s battery from the monitor with USB power delivery.

Description

Precision-engineered for graphics excellence with hardware-calibrated precision (Delta E<2), calman ready calibration, and UHD Nano IPS display
The AOC Graphic Pro U32U3CV delivers outstanding color accuracy right out of the box, courtesy of its hardware calibration achieving Delta E<2 (sRGB). Easily adjust settings for peak performance with the Calman Ready feature. With a remarkable 98% coverage of the DCI P3, 100% of the sRGB and 100% of the Rec 709 color space, it's tailor-made for graphic and photo editing, offering superior quality compared to standard monitors. Its Delta E < 2 accuracy ensures precise color rendering that exceeds human eye perception. Enhanced with a UHD Nano IPS display, Vesa DisplayHDR 400, USB-C docking station, and sleek design, it stands out as the ultimate choice for professionals.

Specifications

Display
HDCP	Yes
Display brightness (typical)	400 cd/m²
Screen shape	Flat
Display number of colours	1.073 billion colours
Native aspect ratio	16:9
Pixel density	140 ppi
DDC/CI	Yes
Colour gamut	98%
Maximum refresh rate	60 Hz
sRGB coverage (typical)	135.3%
HD type	4K Ultra HD
Display technology	LCD
Contrast ratio (dynamic)	50000000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Pixel pitch	0.18159 x 0.18159 mm
Horizontal scan range	30 - 140 kHz
Vertical scan range	23 - 75 Hz
Viewable size, horizontal	69.7 cm
Viewable size, vertical	39.2 cm
Digital horizontal frequency	30 - 140 kHz
Digital vertical frequency	23 - 75 Hz
Backlight type	W-LED
Display resolution	3840 x 2160 pixels
Response time	4 ms
Display diagonal	80 cm (31.5")
Contrast ratio (typical)	1000:1
Surface hardness	3H
Touchscreen	No
High Dynamic Range (HDR) supported	Yes
Panel type	Nano IPS
High Dynamic Range (HDR) technology	DisplayHDR 400
Display diagonal (metric)	80 cm
Haze rate	25%
LED backlight	Yes
Colour gamut standard	DCI-P3
Local dimming	Yes
Response time measurement type	GTG (Gray to Gray)
Anti-glare screen	Yes
Audio
Built-in speaker(s)	Yes
RMS rated power	6 W
Performance
Built-in speaker(s)	Yes
RMS rated power	6 W
Mean time between failures (MTBF)	30000 h
Built-in camera	No
VESA Adaptive Sync support	Yes
Flicker-free technology	Yes
Fast charging	Yes
Low input lag	No
Management features
Plug and Play	Yes
Picture-in-Picture	Yes
Multimedia
Number of speakers	2
Built-in speaker(s)	Yes
RMS rated power	6 W
Built-in camera	No
Power
Power cable length	1.8 m
Power supply type	Internal
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	215 W
Power consumption (standby)	0.3 W
Power consumption (typical)	30.37 W
Power consumption (off)	0.3 W
Input current	3 A
Energy efficiency scale	A to G
Energy efficiency class (SDR)	F
Energy efficiency class (HDR)	G
Energy consumption (SDR) per 1000 hours	32 kWh
Energy consumption (HDR) per 1000 hours	56 kWh
Design
Market positioning	Graphics design
Feet colour	Grey
Certification	WEEE,REACH compliant,RoHs compliant,HF,CB,TUV-GS-Mark,EAC,FCC,Microsoft WHQL
Product colour	Black
Front bezel colour	Black/Silver
Frameless design	Yes
Detachable stand	Yes
Mean time between failures (MTBF)	30000 h
Bezel thickness type	Frameless
Camera
Built-in camera	No
Ports & interfaces
Built-in USB hub	Yes
USB hub version	3.2 Gen 2 (3.1 Gen 2)
USB upstream port type	USB Type-C
Number of upstream ports	2
USB Type-A downstream ports quantity	4
USB Type-C downstream ports quantity	1
Headphone out	Yes
HDMI ports quantity	2
DisplayPorts quantity	1
HDCP	Yes
Audio output	Yes
Headphone outputs	1
HDMI	Yes
AC (power) in	Yes
HDMI version	2.0
DisplayPort version	1.4
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	96 W
USB Type-C DisplayPort Alternate Mode	Yes
Built-in KVM switch	Yes
HDCP version	2.2
Ethernet LAN	Yes
Technical details
Feet colour	Grey
Cable lock slot	Yes
Mean time between failures (MTBF)	30000 h
HDMI	Yes
Product colour	Black
Front bezel colour	Black/Silver
Sustainability certificates	EPEAT Gold, TCO
Doesn't contain	Mercury, PVC/BFR
Warranty period	3 year(s)
Compliance certificates	CE
Power supply type	Internal
Weight (with stand)	8.46 kg
Surface hardness	3H
Touchscreen	No
Network
Ethernet LAN	Yes
Ergonomics
VESA mounting	Yes
Cable lock slot	Yes
Panel mounting interface	100 x 100 mm
Swivelling	Yes
Swivel angle range	-15 - 15°
Tilt angle range	-6.5 - 23°
Pivot	Yes
Pivot angle	-90 - 90°
Plug and Play	Yes
Picture-in-Picture	Yes
Height adjustment	Yes
Cable lock slot type	Kensington
Tilt adjustment	Yes
Adjustable height (max)	15 cm
Operational conditions
Non-operating altitude	0 - 12192 m
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-25 - 55 °C
Operating relative humidity (H-H)	10 - 85%
Storage relative humidity (H-H)	5 - 93%
Operating altitude	0 - 5000 m
Weight & dimensions
Width (with stand)	714.4 mm
Depth (with stand)	258.6 mm
Height (with stand)	609.3 mm
Weight (with stand)	8.46 kg
Weight (without stand)	6.34 kg
Package weight	12.6 kg
Packaging data
Package weight	12.6 kg
Package type	Box
Stand included	Yes
Power cable length	1.8 m
Quick start guide	Yes
Cables included	AC, HDMI, DisplayPort, USB Type-C
DisplayPort cable length	1.8 m
HDMI cable length	1.8 m
Packaging content
Stand included	Yes
Power cable length	1.8 m
Quick start guide	Yes
Cables included	AC, HDMI, DisplayPort, USB Type-C
DisplayPort cable length	1.8 m
HDMI cable length	1.8 m
Sustainability
Sustainability certificates	EPEAT Gold, TCO
Doesn't contain	Mercury, PVC/BFR
Other features
Mean time between failures (MTBF)	30000 h
Certification	WEEE,REACH compliant,RoHs compliant,HF,CB,TUV-GS-Mark,EAC,FCC,Microsoft WHQL
Bezel thickness type	Frameless
Warranty period	3 year(s)
Low input lag	No
Local dimming	Yes
Compliance certificates	CE
Power consumption (max)	215 W
Quick start guide	Yes
HDMI	Yes
Surface hardness	3H
USB Power Delivery up to	96 W
Energy efficiency scale	A to G
USB Type-C DisplayPort Alternate Mode	Yes
Power supply type	Internal
Power cable length	1.8 m
Ethernet LAN	Yes
Touchscreen	No
USB Power Delivery (USB PD)	Yes
Package type	Box
Front bezel colour	Black/Silver
Recycling data
Post-consumer recycled plastic	85%
Recycled content in packaging	80%
Certificates
Certification	WEEE,REACH compliant,RoHs compliant,HF,CB,TUV-GS-Mark,EAC,FCC,Microsoft WHQL
