2-Port PS/2-USB VGA KVM Switch
Setup is fast and easy; simply plug cables into their appropriate ports. There is no software to configure, no installation routines, and no incompatibility problems. Since the CS82U intercepts keyboard input directly, it will work on multiple computing platforms.
Key Features
- Superior video quality - 2048 x 1536; DDC2B
- Computer selection via front panel pushbuttons, hotkeys, and mouse
- Dual Interface - supports computers with PS/2 or USB keyboards and mice
- Video DynaSync™ - Exclusive ATEN technology eliminates bootup display problems and optimizes resolution when switching between ports
Description
The CS82U PS/2-USB KVM Switch is a desktop control unit that allows users to access two computers from a single KVM console (PS/2 or USB keyboard and mouse, and VGA monitor). In addition, CS82U comes with ATEN's new Video DynaSync™ technology, which eliminates boot-up display problems and optimizes resolution.Setup is fast and easy; simply plug cables into their appropriate ports. There is no software to configure, no installation routines, and no incompatibility problems. Since the CS82U intercepts keyboard input directly, it will work on multiple computing platforms.
Specifications
| Ports & interfaces | |
|---|---|
| Console USB ports quantity | 2 |
| Console ports | PS/2, USB A, VGA (D-Sub) |
| USB connector type | USB Type-A |
| Number of computers controlled | 2 |
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Video port type | VGA |
| PS/2 ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| DC-in jack | Yes |
| USB 2.0 Type-A hub ports quantity | 2 |
| Performance | |
| DDC2B support | Yes |
| HD type | QXGA |
| Video bandwidth | 60 Hz |
| Maximum resolution | 2048 x 1536 pixels |
| Scan interval | 3,5,10,20 s |
| Technical details | |
| Product colour | Black, Light grey |
| Rack mounting | No |
| Scan interval | 3,5,10,20 s |
| Push button | Yes |
| LED indicators | Yes |
| Hot keys | Yes |
| Design | |
| Product colour | Black, Light grey |
| Rack mounting | No |
| Push button | Yes |
| LED indicators | Yes |
| Hot keys | Yes |
| Housing material | Metal |
| Display | |
| Built-in display | No |
| Power | |
| Power source | DC |
| Power consumption (typical) | 1.1 W |
| Input voltage | 5 V |
| Video | |
| HD type | QXGA |
| Video bandwidth | 60 Hz |
| Maximum resolution | 2048 x 1536 pixels |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Width | 88 mm |
| Depth | 140 mm |
| Height | 55.5 mm |
| Weight | 540 g |
| Packaging content | |
| Quick installation guide | Yes |
| Manual | Yes |
| Other features | |
| I/O ports | 2x SPHD-18 |
| Push button | Yes |
| Hot keys | Yes |
-
