ATEN PE4104G power distribution unit (PDU) 4 AC outlet(s) 1U Black

4-Outlet IP Control Box

Key Features

• Power Distribution
• Space saving slim form factor
• IEC power outlet
• Separates power for the unit's own power and its power outlets – user interface is still accessible even when an overload condition trips the device’s circuit breaker
• Remote Access
• Remote power control via TCP/IP and a built in 10/100 Ethernet port
• Network Interfaces: TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, ARP, NTP, DNS, SNMP V1&V2&V3, auto sense, Ping, Telnet, Modbus (Over TCP IP)
• Works with web-based eco DC software
• Auto-Ping and Auto-Reboot – once an IP address is linked to one or more outlets, this automatic function will reboot the IP equipment when the communications to the IP address is lost
• Operation
• Local and remote power outlet control (On, Off, Power Cycle) by individual outlets
• Power-on sequencing – users can set the power on sequence and delay time for each port to allow equipment to be turned on in a proper order
• Easy setup and operation via a browser-based user interface
• Security
• Two-level password security
• Strong security features include password protection and advanced encryption technologies – TLS1.2
• Remote authentication support: RADIUS

Description

Engineered to be an intelligent power distribution solution, the PE4104G IP Control Box ships with 4 power outlets in an IEC socket configuration. It provides secure, centralized, intelligent, and remote power management of data center IT equipment to minimize the operating cost.

The PE4104G features the remote power control function, allowing you to control devices attached to the PDU at the PDU device level from practically any location via a TCP/IP connection. The power sequence design eliminates the risks for a power inrush to guarantee reliable operation and protects the overall system health. With the support for eco DC software, it provides an easy method for managing multiple devices, offering an intuitive and user-friendly Graphical User Interface that allows you to configure a PDU device and reboot the device in case any equipment lock-up occurs. The administrators can switch on/off or set a delay time for each power outlet or individual power outlets group whenever, wherever.

The PE4104G boasts a slim, compact form factor and supports desk mount as well as rack mount, ensuring easy installation in confined spaces. It is a smart power control box tailored for hospitality or retail applications, such as digital signages and video walls, for edge computing devices, including routers, servers and cameras, or for any data center environments where there is no need to keep the servers powered on at all times.

Specifications

Design
Product colour	Black
Certification	CE-EMC CE-LVD
Rack capacity	1U
Ports & interfaces
AC outlets quantity	4 AC outlet(s)
AC outlet types	C13 coupler
Power plug	C14 coupler
Ethernet LAN (RJ-45) ports	1
Features
Cable length	3 m
LED indicators	Yes
Certification	CE-EMC CE-LVD
Reset button	Yes
Ergonomics
Cable length	3 m
LED indicators	Yes
Power
Nominal input voltage	100-240 V
Maximum current	10 A
Weight & dimensions
Weight	900 g
Width	200 mm
Depth	115 mm
Height	44 mm
Packaging content
Cables included	AC
Manual	Yes
Rack mount kit	Yes
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%
Technical details
Compliance certificates	CE
