The DeepCool PL750D is a 750W ATX power supply for PC builders upgrading a desktop or putting together a system with a current graphics card. Its ATX12V V3.1 design and mix of motherboard, CPU, PCIe and SATA connections suit a range of standard desktop builds.
The DeepCool PL750D is a 750W non-modular power supply unit (PSU) that complies with the Intel ATX12V V3.1 standard. Designed for reliability and efficiency, it features a 120mm hydro-bearing fan for optimal cooling and carries an 80 PLUS Bronze certification, ensuring at least 85% energy efficiency under typical loads.
Special Features
- The inclusion of a 16AWG 12VHPWR cable enables support for next-generation GPUs with higher power demands. The PL750D also uses premium electrolytic capacitors to ensure enhanced durability and performance.
Specification
| Specification | Detail |
|---|---|
| Form Factor | ATX12V V3.1 |
| Dimensions | 150 mm (W) x 140 mm (L) x 86 mm (H) |
| Efficiency Certification | 80 PLUS Bronze |
| Fan Size | 120 mm |
| Fan Bearing | Hydro Bearing |
| Topology | Active PFC + DC to DC |
| Capacitors | Chinese Electrolytic Capacitors |
| Hold-Up Time | =16 ms |
| Efficiency | =85% under typical load (50% loading) |
| Protections | Over Power Protection (OPP) Over Voltage Protection (OVP) Short Circuit Protection (SCP) Over Temperature Protection (OTP) Over Current Protection (OCP) Under Voltage Protection (UVP) Surge & Inrush Protection (SIP) No Load Operation (NLO) |
| Operating Temperature | 0°C to 40°C |
| Regulatory Certifications | CE, FCC, CCC, RCM, EAC, BIS, CAN ICES-003(B), NMB-003(B), TUV-RH |
| Environmental Compliance | WEEE, RoHS |
| Mean Time Between Failures (MTBF) | 100,000 hours |
| Connectors | 1 x 20+4 Pin ATX (Motherboard Power) 2 x 4+4 Pin ATX12V (CPU Power) 3 x 6+2 Pin PCIe (GPU Power) 8 x SATA Power 2 x 4-Pin Molex (Peripheral Power) 1 x 16-Pin (12+4) 12VHPWR Connector (PCIe 5.0) |
| Warranty | Backed by a 5-year limited warranty, the DeepCool PL750D delivers stable, reliable power for both legacy and next-gen PC builds. |
-
