DELL Pro Max GB10 FCM1253 128 GB LPDDR5x-SDRAM 2 TB SSD DGX OS Mini PC Black

GB10 (16MB Cache), 128GB LPDDR5x-SDRAM, 2000GB SSD, NVIDIA Blackwell, LAN, WLAN, Bluetooth, NVIDIA DGX OS 7, L6 Chassis

Key Features

• DGX OS
• GB10 (16MB Cache)
• 128GB LPDDR5x-SDRAM & 2000GB SSD

Reasons To Buy

Massive output. Small footprint.

Delivering exceptional performance in a compact design, this system features the cutting-edge NVIDIA® Grace-Blackwell architecture. With NVLink-C2C for ultra-low latency and 128GB LPDDR5X unified memory, it streamlines data sharing between CPU and GPU, enhancing efficiency and supporting demanding AI models like GenAI and LLMs.

Powerful, localised AI solutions

Take on AI and data science workloads with ease, powered by enabled large model local inferencing-up to 200B parameters.

Scale
Connect two Dell Pro Max with GB10 utilising the ConnectX-7 port to work with larger models and workloads.
Build
NVIDIA AI software stack provides developers with tools to build and run AI workflows.
Secure
Data stays local without having to transfer to external locations.
Control
Your own personal AI cloud - no contention for data centre compute or expense of cloud instances.

Scaled for success

Meet next-level efficiency using scalable inferencing with faster performance compared to traditional multi-GPU setups. Equipped with the ConnectX-7 SmartNIC and 200GbE connectivity, this system enables seamless high-speed clustering across nodes to run large models efficiently. With Remote Direct Memory Access (RDMA) and GPUDirect, CPUs and GPUs can access each other’s memory directly, eliminating overhead and enabling secure, shared workloads.

Seamless performance

Stable, fully-tested environments efficiently run AI, machine learning, and analytics workloads ensuring reliability and maximum productivity for advanced applications.The NVIDIA DGX OS, built on Ubuntu Linux, is tailored with system-specific optimisations and additional drivers for simplified efficiency.

Innovate securely at the edge

The edge is where your data comes to life. With TPM 2.0, fast AI data collection and secure analytics on the edge you’ll get faster discoveries, streamlined workflows with the ability to innovate effectively. Working at the source empowers you to uncover hidden efficiencies, create better experiences, and deliver solutions that truly drive progress.

Regulatory Product Compliance & Environmental

Dell Technologies is committed to compliance with the laws and regulations in each country into which the company ships it's products. Dell products are designed and tested to meet the appropriate worldwide standards for Product Safety, Electromagnetic Compatibility, Ergonomics, and other regulatory compulsory requirements when used for their intended purpose.

In addition, Dell products are developed with design for the environment in mind. Our environmental stewardship program drives conservation of product energy consumption, develops methods to reduce or eliminate materials for disposal, prolongs product life span, and provides effective and convenient equipment recovery solutions.

Description

Compact design for optimized AI workloads
Dell Pro Max with GB10 an AI Accelerator provides compact design with powerful performance for local AI inferencing, AI development, and versatile Edge use cases.

Specifications

Processor
Processor cache	16 MB
Processor model	GB10
Processor manufacturer	Nvidia
Processor cores	20
Neural processor unit (NPU)
NPU performance up to	13 TOPs
Memory
Internal memory	128 GB
Maximum internal memory	128 GB
Internal memory type	LPDDR5x-SDRAM
Memory data transfer rate	8533 MT/s
Storage
Storage media	SSD
Number of storage drives installed	1
Optical drive type	No
SSD interface	PCI Express 4.0
SSD capacity	2 TB
Number of SSDs installed	1
Total storage capacity	2 TB
SSD form factor	M.2
Total SSDs capacity	2 TB
NVMe	Yes
M.2 SSD size	2230 (22 x 30 mm)
Graphics
Discrete graphics card	No
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card model	NVIDIA Blackwell
On-board GPU manufacturer	NVIDIA
Optical drive
Optical drive type	No
Network
Ethernet LAN	Yes
Wi-Fi	Yes
Bluetooth	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Ethernet LAN data rates	10,100,1000,10000 Mbit/s
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
WLAN controller manufacturer	AzureWare
LAN controller	NVIDIA ConnectX-7
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Thunderbolt 3 ports quantity	0
HDMI version	2.1a
USB 2.0 ports quantity	0
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 2x2 Type-C ports quantity	3
USB Type-C DisplayPort Alternate Mode	Yes
Technical details
Product type	Mini PC
Trusted Platform Module (TPM)	Yes
Product colour	Black
Box contents	E5 Power Cord 1M for Europe
Doesn't contain	PVC/BFR
Design
Product colour	Black
Performance
Product type	Mini PC
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Software
Operating system installed	DGX OS
Power
Power supply input voltage	100 - 240 V
Power supply	280 W
Operational conditions
Operating altitude	-15.2 - 3048 m
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating temperature (T-T)	0 - 35 °C
Non-operating altitude	-15.2 - 10668 m
Operating vibration	0.66 G
Non-operating vibration	1.3 G
Operating shock	110 G
Non-operating shock	160 G
Sustainability
Doesn't contain	PVC/BFR
Total carbon footprint (kg of CO2e)	427
Weight & dimensions
Width	150 mm
Depth	150 mm
Height	51 mm
Weight	1.34 kg
Packaging content
Display included	No
Display
Display included	No
Carbon footprint
Total carbon footprint (kg of CO2e)	427
Total carbon emissions, standard deviation (kg of CO2e)	110
PAIA version	PAIA 1.5.1, 2025
Carbon emissions, energy usage (kg of CO2e)	99.064
Carbon emissions, manufacturing (kg of CO2e)	258.762
Carbon emissions, logistics (kg of CO2e)	61.488
Carbon emissions, end-of-life (kg of CO2e)	7.686
Other features
Trusted Platform Module (TPM)	Yes
On-board graphics card	Yes
Processor manufacturer	Nvidia
Doesn't contain	PVC/BFR
