DrayTek VigorAP 918R 866 Mbit/s White Power over Ethernet (PoE)

Outdoor Mesh 802.11ac Wireless Access Point with Directional Antenna and PoE-PSE Output, 2.4GHz, 5GHz, white

Description

VigorAP 918R is a wireless access point designed for outdoor environments. It is ideal for providing wireless access to users and devices in any outdoor scenario, including restaurants, gardens, marinas, educational premises or, really, anywhere where outdoor access is needed.

The VigorAP 918R is a dual-band 802.11ac Wave 2 wireless access point and range extender that can be used a part of a DrayTek Mesh Wireless solution, designed to eliminate wireless drop outs, stuttering videos, slow download speeds, poor signal and Wi-Fi dead zones. One access point acts as the controller (Mesh root) and in total up to 8 access points create an easy to manage wireless mesh. Extend coverage without running expensive cabling.

Initial setup of the VigorAP 918R is easy with the DrayTek Wireless app, whether it's creating a new Mesh network or being set up in AP and Range Extender modes, the Quick Start Wizard assists throughout.
Manage the VigorAP 918R centrally through the VigorACS central management platform, VigorConnect, Router AP Management, or simply on its own as a stand-alone access point.

The VigorAP 918R has the flexibility to be used how you need it, in any environment.

Specifications

Data transmission
Maximum data transfer rate	866 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
Wireless isolation	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Syslog	Yes
Reset button	Yes
Firmware upgradeable	Yes
Web-based management	Yes
VLAN support	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Channels quantity	3 channels
Maximum data transfer rate	866 Mbit/s
MIMO type	Multi User MIMO
MIMO	Yes
Wireless LAN features
Channels quantity	3 channels
Network
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Management features
VLAN support	Yes
Syslog	Yes
Firmware upgradeable	Yes
Web-based management	Yes
Local AP management	Telnet
Command-line interface (CLI)	Yes
Features
2.4 GHz	Yes
5 GHz	Yes
Wireless isolation	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
VLAN support	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Channels quantity	3 channels
Maximum data transfer rate	866 Mbit/s
Fast roaming	Yes
MIMO type	Multi User MIMO
MIMO	Yes
Maximum data transfer rate (2.4 GHz)	400 Mbit/s
Maximum data transfer rate (5 GHz)	866 Mbit/s
WLAN channel features	WLAN channel management
Security
IP address filtering	Yes
Security algorithms	HTTPS, WEP, WPA, WPA2, WPS
MAC address filtering	Yes
Service Set Identifier (SSID) features	Hidden SSID, Multiple SSIDs
Protocols
DHCP server	Yes
DHCP client	Yes
Ports & interfaces
Internal RJ-45 ports quantity	1
Ethernet LAN (RJ-45) ports	1
Power
Power consumption (max)	43.2 W
Power over Ethernet (PoE)	Yes
Design
International Protection (IP) code	IP67
Placement	Pole, Wall
Product colour	White
Reset button	Yes
Antenna
Antenna type	Internal
Polarization	Dual polarization
Antennas quantity	2
Antenna gain level (max)	11 dBi
Antenna connector type	RP-SMA
Antenna direction type	Directional
Antenna features	Detachable antenna
Technical details
Reset button	Yes
Firmware upgradeable	Yes
Polarization	Dual polarization
Harmonized System (HS) code	85176990
Compliance certificates	RoHS
Software
Fast roaming	Yes
Local AP management	Telnet
Weight & dimensions
Width	161 mm
Depth	72 mm
Weight	1 kg
Height	460 mm
Packaging data
Quick start guide	Yes
Cables included	LAN (RJ-45)
Packaging content
Quick start guide	Yes
Cables included	LAN (RJ-45)
Operational conditions
Operating relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	-40 - 70 °C
Other features
Polarization	Dual polarization
Logistics data
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
