Epson EB-L520U

EB-L520U

Key Features

• High brightness, scalable size: Provides 5,200 lumens high-brightness display at up to 500"
• Premium display features: Full HD, supports 4K input, edge-blending and geometric correction
• Unrestricted viewing: Free from pixilation, glare, fingerprints and a central bevel
• Social distancing support: Scalable display meets the needs of every audience configuration
• Plug, click and collaborate: Collaborate using Epson’s wireless presentation system - ELPWP10

Reasons To Buy

Legal Statement

Complies with The UK Product Security and Telecommunications Infrastructure (Product Security) requirements. Epson will provide security updates for 7 years from purchase

Description

WUXGA laser display
Deliver professional content with sharp images and bright colours to any audience. The EB-L520U is designed to project a scalable laser display up to 500 inches, and offers a range of connectivity options to make content sharing an easy, seamless experience.


Featuring 5,200 lumens high-brightness capability, along with Full HD, WUXGA, 16:6 wide screen, support for 4K input and detail enhancement technology, it gives users brighter, more vivid displays of up to 500”.


Providing more premium features than you would typically expect to find in this display class, the EB-L520U delivers edge-blending and geometric correction to achieve one seamless large-format display. And for multimedia content, you can playback content without any lagging, and create playlists and set schedules directly from USB memory, all thanks to H.264 advanced video coding and the Epson Content Manager.


Flexibility is another hallmark of this display solution - a split-screen function allows two or four images from different sources to be combined in one large display; wired or optional wireless{s1 with support for Miracast{s1 makes connectivity simple and straightforward; and HDBaseT content can be shared and distributed without compromising on quality.


Thanks to the renowned market leading{s2 reliability of Epson laser displays, this fit and forget solution eliminates the need for regular maintenance. And for added confidence the EB-L520U comes with a standard 3-year warranty to provide lasting peace of mind.

Specifications

Projector
Number of colours	1.07 billion colours
Projector native resolution	WUXGA (1920x1200)
Native aspect ratio	16:10
Screen size compatibility	1270 - 12700 mm (50 - 500")
Contrast ratio (typical)	2500000:1
Zoom ratio	1.6:1
Zoom capability	Yes
Vertical scan range	192 - 240 Hz
Projector brightness (economic mode)	3640 ANSI lumens
Matrix size	1.7 cm (0.67")
Keystone correction, vertical	-30 - 30°
Keystone correction, horizontal	-30 - 30°
Projection technology	3LCD
Projector brightness	5200 ANSI lumens
Zoom type	Manual
Lamps
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Light source
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Lens system
Zoom ratio	1.6:1
Zoom capability	Yes
Focus	Manual
Focal length range	20 - 31.8 mm
Aperture range (F-F)	1.5 - 1.7
Throw ratio	1.35 - 2.2:1
Zoom type	Manual
Scanning frequency
Vertical scan range	192 - 240 Hz
Video
Video processing	10 bit
Video colour modes	Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode
Analog signal format system	Not supported
Full HD	Yes
3D	No
Audio
Built-in speaker(s)	Yes
Number of built-in speakers	1
RMS rated power	10 W
Ports & interfaces
USB 2.0 Type-B ports quantity	1
VGA (D-Sub) ports quantity	3
HDMI ports quantity	2
USB 2.0 ports quantity	2
Audio (L/R) in	1
Serial interface type	RS-232C
DVI port	No
Network
Ethernet LAN	Yes
Wi-Fi	Yes
Wi-Fi standards	802.11a, Wi-Fi 4 (802.11n)
Storage
Card reader integrated	No
Sound emission
Noise level	31 dB
Noise level (economic mode)	23 dB
Technical details
Product colour	White
Products per pallet	14 pc(s)
Quantity per pack	1 pc(s)
Pallet gross weight	0 g
Products per pallet (UK)	14 pc(s)
Pallet weight (UK)	0 g
USB display function	3 in 1: Image / Mouse / Sound
Sustainability certificates	TCO
Performance
Market positioning	Presentation
Vertical scan range	192 - 240 Hz
Noise level	31 dB
Noise level (economic mode)	23 dB
Features
Noise level	31 dB
Noise level (economic mode)	23 dB
Country of origin	Philippines
Multimedia
Built-in speaker(s)	Yes
Number of built-in speakers	1
RMS rated power	10 W
Design
Market positioning	Presentation
Product type	Standard throw projector
Cable lock slot type	Kensington
Product colour	White
Cable lock slot	Yes
Placement	Ceiling, Desktop, Floor, Wall
Display
Built-in display	No
Power
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power source	AC
Power consumption (typical)	293 W
Power consumption (standby)	0.3 W
Power consumption (economy mode)	223 W
Packaging data
Package width	540 mm
Package depth	530 mm
Package height	210 mm
Package weight	10.4 kg
Security
Cable lock slot type	Kensington
Cable lock slot	Yes
Software
Bundled software	EasyMP Multi PC Projection
Software support	via: AMX, Crestron (Network), Control4, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
Supplier features
Harmonized System (HS) code	85286200
Operational conditions
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90%
Weight & dimensions
Package width	540 mm
Package depth	530 mm
Package height	210 mm
Weight	7.7 kg
Width	440 mm
Depth	122 mm
Height	304 mm
Package weight	10.4 kg
Packaging content
Remote control included	Yes
Warranty card	Yes
Cables included	AC, HDMI
Bundled software	EasyMP Multi PC Projection
Batteries included	Yes
Logistics data
Products per pallet	14 pc(s)
Quantity per pack	1 pc(s)
Pallet gross weight	0 g
Products per pallet (UK)	14 pc(s)
Pallet weight (UK)	0 g
Harmonized System (HS) code	85286200
Other features
Power consumption (economy mode)	223 W
