Epson EB-L720U

EB-L720U

Key Features

• High brightness, scalable size: Provides 7,000 lumens high-brightness display at up to 500"
• Premium display features: Full HD, 4K support, edge-blending and geometric correction
• Unrestricted viewing: Free from pixilation, glare, fingerprints and a central bevel
• Social distancing support: Scalable display meets the needs of every audience configuration
• Plug, click and collaborate: Collaborate using Epson’s wireless presentation system - ELPWP10

Reasons To Buy

Legal Statement

Complies with The UK Product Security and Telecommunications Infrastructure (Product Security) requirements. Epson will provide security updates for 7 years from purchase

Description

WUXGA laser display
The EB-L720U delivers exceptional image quality, focussing on professional content delivery and display performance. Designed around ease of use, up to a 500" display size, affordability and sustainability, it's the ideal imaging solution for today's professional world.


Featuring a powerful 7,000 lumens high-brightness capability, along with Full HD, WUXGA, 16:6 wide screen, support for 4K input and detail enhancement technology, it gives users brighter, more vivid displays of up to 500”.


Providing more premium features than you would typically expect to find in this display class, the EB-L720U delivers edge-blending and rich geometric correction to achieve one seamless large-format display. And for multimedia content, you can playback content without any lagging, and create playlists and set schedules directly from USB memory, all thanks to H.264 advanced video coding and the Epson Content Manager.


Flexibility is another hallmark of this display solution - a split-screen function allows two or four images from different sources to be combined in one large display; wired or optional wireless{s1 with support for Miracast{s1 makes connectivity simple and straightforward; and HDBaseT content can be shared and distributed without compromising on quality.


Thanks to the renowned market leading{s2 reliability of Epson laser displays, this fit and forget solution eliminates the need for regular maintenance. And for added confidence the EB-L720U comes with a standard 3-year warranty to provide lasting peace of mind.

Specifications

Projector
Number of colours	1.07 billion colours
Projector native resolution	WUXGA (1920x1200)
Native aspect ratio	16:10
Screen size compatibility	1270 - 12700 mm (50 - 500")
Contrast ratio (typical)	2500000:1
Zoom ratio	1.6:1
Zoom capability	Yes
Vertical scan range	192 - 240 Hz
Projector brightness (economic mode)	4900 ANSI lumens
Matrix size	1.7 cm (0.67")
Keystone correction, vertical	-30 - 30°
Keystone correction, horizontal	-30 - 30°
Projection technology	3LCD
Projector brightness	7000 ANSI lumens
Zoom type	Manual
Lamps
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Light source
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Lens system
Zoom ratio	1.6:1
Zoom capability	Yes
Focus	Manual
Focal length range	20 - 31.8 mm
Aperture range (F-F)	1.5 - 1.7
Throw ratio	1.35 - 2.20:1
Offset	27%
Zoom type	Manual
Scanning frequency
Vertical scan range	192 - 240 Hz
Video
Video processing	10 bit
Video colour modes	Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode
Full HD	Yes
Audio
Built-in speaker(s)	Yes
Number of built-in speakers	1
RMS rated power	10 W
Ports & interfaces
HDMI connector type	Full-size
HDBaseT port	Yes
USB 2.0 Type-B ports quantity	1
VGA (D-Sub) ports quantity	3
HDMI ports quantity	2
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	1
Composite video in	0
Audio (L/R) in	0
Serial interface type	RS-232C
PC Audio out	Yes
PC Audio in	Yes
DVI port	No
Component video (YPbPr/YCbCr) in	0
Network
Smart TV	No
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	No
Ethernet LAN (RJ-45) ports	1
Storage
Card reader integrated	No
Sound emission
Noise level	39 dB
Noise level (economic mode)	27 dB
Technical details
Product colour	White
Products per pallet	14 pc(s)
Quantity per pack	1 pc(s)
Pallet gross weight	0 g
Products per pallet (UK)	14 pc(s)
Pallet weight (UK)	0 g
USB display function	3 in 1: Image / Mouse / Sound
Sustainability certificates	TCO
Performance
Vertical scan range	192 - 240 Hz
Noise level	39 dB
Noise level (economic mode)	27 dB
Features
Interactive	No
Noise level	39 dB
Noise level (economic mode)	27 dB
Country of origin	China
Multimedia
Built-in speaker(s)	Yes
Number of built-in speakers	1
RMS rated power	10 W
Design
Product type	Standard throw projector
Cable lock slot type	Kensington
Product colour	White
Cable lock slot	Yes
Placement	Ceiling, Desktop, Floor, Wall
Display
Built-in display	No
Power
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power source	AC
Power consumption (typical)	345 W
Power consumption (standby)	0.3 W
Power consumption (economy mode)	258 W
Packaging data
Package width	540 mm
Package depth	530 mm
Package height	210 mm
Package weight	10.8 kg
Security
Cable lock slot type	Kensington
Cable lock slot	Yes
Software
Bundled software	EasyMP Multi PC Projection
Software support	via: AMX, Crestron (Network), Control4, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
Supplier features
Harmonized System (HS) code	85286200
Operational conditions
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90%
Weight & dimensions
Package width	540 mm
Package depth	530 mm
Package height	210 mm
Weight	7.8 kg
Width	440 mm
Depth	122 mm
Height	304 mm
Package weight	10.8 kg
Packaging content
Remote control included	Yes
Warranty card	Yes
Manual	Yes
Cables included	AC, HDMI
Bundled software	EasyMP Multi PC Projection
Batteries included	Yes
WLAN adapter included	Yes
Logistics data
Products per pallet	14 pc(s)
Quantity per pack	1 pc(s)
Pallet gross weight	0 g
Products per pallet (UK)	14 pc(s)
Pallet weight (UK)	0 g
Harmonized System (HS) code	85286200
Other features
Power consumption (economy mode)	258 W
