Epson Lens - ELPLU03S - Short throw off axis 1 - EB-PU Series

Description

Epson ELPLU03S

Add Short-Throw Flexibility to Pro L Projectors up to 20000 Lumens
Bring added flexibility to Epson? Pro L projectors up to 20000 lumens and Pro G7000 Series projectors with the Short-throw #1 Zoom Lens ELPLU03S. Ideal for projecting large high-quality images in narrow spaces this interchangeable lens supports screen sizes of 80 to 1000 and provides a wider lens shift for 1080p sources compared to our previous generation lens (ELPLU03).

Key Features
• Interchangeable Lens: For Pro L projectors up to 20000 lumens and Pro G7000 Series projectors.
• Convenient Short-Throw Design: Ideal for projecting a large image in narrow spaces.
• Wide Lens Shift: For added flexibility.
• Easy Integration: Supports select Epson laser projectors up to 20000 lumens.
• High-Quality Design: 80 to 1000 screen size support; 2.0 to 2.3 F-number; 11.1 mm to 13.1 mm focal length.
• Zoom Ratio: 1 to 1.2.
• Weight: 5 lbs (2300 g).
• Up to 8000-Lumen Projectors: 0.65 to 0.78 WUXGA/WXGA throw ratio; lens shift—vertical: -67 percent to +67 percent (H Center) horizontal: -30 percent to +30 percent (V Center).
• 9000- to 20000-Lumen Projectors: 0.48 to 0.57 WUXGA throw ratio; lens shift—vertical: -24 percent to +24 percent (H Center) horizontal: -10 percent to +10 percent (V Center).
• Enhanced Lens Shift: provides wider lens shift for 1080p sources compared to our previous generation lens (ELPLU03).

Works With
• Pro L1060WNL WXGA 3LCD Laser Projector.
• Pro L1070W WXGA 3LCD Laser Projector.
• Pro L1070WNL WXGA 3LCD Laser Projector.
• Pro L1060W WXGA 3LCD Laser Projector.
• Pro L12000QNL Native 4K 3LCD Laser Projector Without Lens.
• Pro L12002QNL Native 4K 3LCD Laser Projector Without Lens.
• Pro L1060U WUXGA 3LCD Laser Projector with 4K Enhancement.
• Pro L1060UNL WUXGA 3LCD Laser Projector with 4K Enhancement.
• Pro L1070U WUXGA 3LCD Laser Projector with 4K Enhancement.

• Up to 8500-lumen projectors?- 0.65 to 0.78 WUXGA/WXGA throw ratio; lens shift vertical: -67 percent to +67 percent horizontal: -30 percent to +30 percent

• 9000- to 20000-lumen projectors?- 0.48 to 0.57 WUXGA throw ratio; lens shift vertical: -24 percent to +24 percent horizontal: -10 percent to +10 percent

• EB-PQ Series 4K Projectors?- 0.46 – 0.56 throw ratio; vertical: -18% to +18% horizontal: -6% to +6%

Specifications
