Fractal Design Define 7 Midi Tower Black

Define 7 Black Solid, 57.7L, 6 x 3.5"/2.5" SSD/HDD Trays, 7 + 2 Expansion slots, E-ATX (max 285 mm) / ATX / mATX / mITX, w/o PSU

Key Features

• New chassis design opens up to fully expose the case interior
• Anodized aluminum front panel with reversible dual-handed hinges
• Multibracket converts unused fan positions to HDD, SSD or pump mounts

Reasons To Buy

Cable management

Integrated cable guides with Velcro ties simplifies cable management behind the board

Nexus+ 2 fan hub

Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans

Type-C interface

Five front USB ports including one USB 3.1 Gen 2 Type-C with fast charging and speeds up to 10Gbps

Description

The Define 7 is the latest pinnacle of the renowned Define series, setting a new standard for what you should expect from a mid-tower case when it comes to modularity, flexibility and ease of use.

Introducing the Define 7 series

Re-defining versatility

Open and interchangeable

Swap in the ventilated panel to add three filtered fan positions; remove the entire top to build and route with zero hindrance.

Superior airflow by design

Three Dynamic X2 GP-14 fans come preinstalled with room to expand up to a total of nine fans.

- Impressive cooling capacity with a total of nine 140 mm or 120 mm fan mounting positions
- Easy-to-clean high airflow nylon filters with full PSU coverage and convenient front access
- The single 5.25” ODD bay can be converted to an additional 140 mm front fan mount with filtered louver covering.

Open layout for massive headroom

You’ll find more than enough space for your custom water loop with large reservoirs and radiators up to 420 mm in the default Open Layout.

- Adaptable dual-layout interior design fits large motherboards up to 285 mm E-ATX
- Support for radiators up to 360 mm in front, 420 mm up top, or 280 mm in the base

6 SSD/HDD trays + 2 SSD brackets + 1 Multibracket included

Superlative storage

Convert to Storage Layout and install up to 14 HDDs alongside four dedicated SSDs mounts

- 6 universal HDD/SSD brackets included with 14 positions total in Storage Layout
- 2 dedicated SSD brackets included with 4 positions total
- Versatile Multibracket converts any unused fan position to an HDD, SSD or pump mount
- Sturdy new HDD cage design with vibration damped trays

Exceptionally silent

Silence-optimized construction with industrial sound-damped front, top, and side panels

Cable management

Integrated cable guides with Velcro ties simplifies cable management behind the board.

Nexus+ 2 fan hub

Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans.

Type-C interface

Five front USB ports including one USB 3.1 Gen 2 Type-C with fast charging and speeds up to 10Gbps.

Versatile new Multibracket

The included Multibracket lets you convert any unused fan position to an HDD, SSD or pump mount.

Specifications

Design
Volume	57.7 L
Anti-dust filter	Yes
Number of external 5.25" bays	1
Material	Aluminium, Steel
Number of 5.25" bays	1
Number of 3.5" bays	6
Number of 2.5" bays	2
Number of internal 3.5" bays	6
Supported motherboard form factors	ATX, micro ATX, Micro-ITX
Suitable for	Gaming
Side window	No
Reset button	Yes
LED indicators	Yes
Illumination	No
Cable management	Yes
Product colour	Black
Number of expansion slots	9
Maximum CPU cooler height	18.5 cm
Maximum graphics card length	49.1 cm
Maximum PSU length	25 cm
Type	PC
Form factor	Midi Tower
On/off button	Yes
Tempered glass panel(s)	No
Technical details
Number of 5.25" bays	1
Number of 3.5" bays	6
Number of 2.5" bays	2
Number of internal 3.5" bays	6
Supported motherboard form factors	ATX, micro ATX, Micro-ITX
Supported HDD sizes	2.5,3.5"
Suitable for	Gaming
Side window	No
Reset button	Yes
Product colour	Black
Number of expansion slots	9
Maximum CPU cooler height	18.5 cm
Maximum graphics card length	49.1 cm
Maximum PSU length	25 cm
Type	PC
Form factor	Midi Tower
Harmonized System (HS) code	84733080
Material
Material	Aluminium, Steel
Indication
LED indicators	Yes
Illumination	No
Ergonomics
Reset button	Yes
LED indicators	Yes
Cable management	Yes
On/off button	Yes
Power supply
Number of power supply units	1
Supported power supply form factors	ATX
Power supply included	No
Power supply location	Bottom
Ports & interfaces
USB 3.2 Gen 2x2 Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 2.0 ports quantity	2
Cooling
Front radiator installed	No
Front radiator sizes supported	280,360 mm
Rear radiator installed	Yes
Top radiator installed	No
Top radiator sizes supported	360,420 mm
Rear radiator fan size installed	120
Front fans installed	2x 140 mm
Number of front fans supported (max)	3
Front fans diameters supported	120,140 mm
Rear fans installed	1x 140 mm
Number of rear fans supported (max)	1
Rear fans diameters supported	120,140 mm
Number of top fans supported (max)	3
Top fans diameters supported	120,140 mm
Number of bottom fans supported (max)	2
Bottom fans diameters supported	120,140 mm
Liquid cooling capability	Yes
Bottom radiator sizes supported	240,280 mm
Storage
Supported HDD sizes	2.5,3.5"
Packaging content
Manual	Yes
Weight & dimensions
Volume	57.7 L
Width	240 mm
Depth	547 mm
Height	475 mm
Weight	13.5 kg
Packaging data
Manual	Yes
Logistics data
Harmonized System (HS) code	84733080
Other features
Volume	57.7 L
Manual	Yes
Harmonized System (HS) code	84733080
