iiyama TW1623AS-B3P computer monitor 39.6 cm (15.6") 1920 x 1080 pixels Full HD LED Touchscreen Black

15.6” PCAP 10pt touchscreen PC with Android, PoE Technology and iiSignage²

Reasons To Buy

Connectivity

The RJ45 (LAN) connector supporting Power over Ethernet technology (POE) allows to provide both data connection and power by a single cable, which simplifies installation in areas where many cables would interfere with the environment.

Android OS

Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.

iiSignage²

iiSignage² is our digital signage content management platform to easily show and control your content and to manage your displays in a secure way. The Content Management System (CMS) gives you total control of your messaging and advertising remotely and safely.

Description

The ProLite TW1623AS-B3P is a smart and intuitive 15.6" touch panel PC, designed for high-traffic environments such as meeting rooms, info points, or hospitality spaces. Its 10-point PCAP touch technology ensures smooth and precise interaction. Powered by Android 13, and equipped with powerful hardware, it allows easy installation of apps directly on the device - making it a all-in-one solution. Thanks to Power over Ethernet (PoE), both power and data are delivered through a single cable, simplifying installation and reducing additional cables. With a built-in microphone and speakers, the TW1623AS-B3P delivers seamless, modern interaction in any smart space. Additionally, it integrates effortlessly with iiSignage² , iiyama’s Content Management System (CMS), giving you full control over your messages and advertising, in landscape portrait and face-up position.

Specifications

Display
HDCP	Yes
Display brightness (typical)	450 cd/m²
Display number of colours	16.7 million colours
Native aspect ratio	16:9
HD type	Full HD
Display technology	LED
Viewing angle, horizontal	170°
Viewing angle, vertical	170°
Pixel pitch	0.1792 x 0.1792 mm
Viewable size, horizontal	34.4 cm
Viewable size, vertical	19.4 cm
Display resolution	1920 x 1080 pixels
Response time	30 ms
Display diagonal	39.6 cm (15.6")
Contrast ratio (typical)	1000:1
Surface hardness	6H
Touchscreen	Yes
Number of simultaneous touchpoints	10
Panel type	IPS
Colour depth	8 bit
Display diagonal (metric)	39.5 cm
Touch technology	Multi-touch
Touchscreen technology	Projected capacitive system
Display brightness	385 cd/m²
Response time measurement type	GTG (Gray to Gray)
Audio
Built-in speaker(s)	Yes
RMS rated power	4 W
Performance
Built-in speaker(s)	Yes
RMS rated power	4 W
Compatible memory cards	SD
Card reader integrated	Yes
Operating system installed	Android
Operating system version	13
Operating hours (hours/days)	24/7
Management features
On Screen Display (OSD)	Yes
Network
Ethernet LAN (RJ-45) ports	1
Bluetooth	Yes
Bluetooth version	5.2
Wi-Fi standards	Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11a, 802.11b
Wi-Fi	Yes
Ethernet LAN	Yes
Multimedia
Number of speakers	2
Built-in speaker(s)	Yes
RMS rated power	4 W
Design
Certification	CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA
Product colour	Black
Front bezel colour	Black
Glass thickness	1.8 mm
Ports & interfaces
USB version	2.0
HDMI ports quantity	1
HDCP	Yes
Audio input	Mini Jack
Microphone in	Yes
Compatible memory cards	SD
Card reader integrated	Yes
Mini HDMI ports quantity	1
USB Touch port	Yes
Bluetooth	Yes
Bluetooth version	5.2
Wi-Fi standards	Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11a, 802.11b
Wi-Fi	Yes
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	1
Technical details
Placement supported	Indoor
Compatible memory cards	SD
Card reader integrated	Yes
Product colour	Black
User controls	Power switch, volume/ button +, volume/ button -
Front bezel colour	Black
Sustainability certificates	ErP
Compliance certificates	CE, EAC, REACH, RoHS, UKCA, WEEE
Packaging content	AC adapter, interchangeable plugs (EU/UK)
Brightness	385 cd/m²
Built-in processor	Yes
Google applications	Google Chrome, Gmail, Google Calendar
Power supply type	External
Active display area (W x H)	344.2 x 193.6 mm
Weight (with stand)	1.5 kg
Touch method	finger, glove (latex), capacitive stylus
Surface hardness	6H
Touchscreen	Yes
Number of simultaneous touchpoints	10
Ergonomics
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
On Screen Display (OSD)	Yes
Cable management	Yes
Power
Power supply type	External
Power consumption (standby)	0.5 W
Power consumption (typical)	9 W
Power consumption (off)	0.3 W
AC adapter output voltage	12 V
Weight & dimensions
Width (with stand)	387 mm
Depth (with stand)	30.5 mm
Height (with stand)	244 mm
Weight (with stand)	1.5 kg
Package width	477 mm
Package depth	75 mm
Package height	298 mm
Package weight	2.45 kg
Width	387 mm
Weight	1.5 kg
Height	244 mm
Packaging data
Package width	477 mm
Package depth	75 mm
Package height	298 mm
Package weight	2.45 kg
AC adapter included	Yes
Quick start guide	Yes
Power adapter included	Yes
Packaging content
Quick start guide	Yes
Power adapter included	Yes
AC adapter included	Yes
Sustainability
Sustainability certificates	ErP
Thin Client
Operating system installed	Android
Processor cores	4
Processor frequency	2 GHz
Processor family	ARM Rockchip
Processor model	RK3568
Processor architecture	ARM Cortex-A55
Other features
Packaging content	AC adapter, interchangeable plugs (EU/UK)
Brightness	385 cd/m²
Built-in processor	Yes
Google applications	Google Chrome, Gmail, Google Calendar
Active display area (W x H)	344.2 x 193.6 mm
USB ports quantity	3
AC adapter included	Yes
Placement supported	Indoor
Certification	CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA
Ethernet LAN (RJ-45) ports	1
User controls	Power switch, volume/ button +, volume/ button -
Touch method	finger, glove (latex), capacitive stylus
Width	387 mm
Weight	1.5 kg
Height	244 mm
Compliance certificates	CE, EAC, REACH, RoHS, UKCA, WEEE
Control panel	Power switch, volume/ button +, volume/ button -
Bluetooth	Yes
Bluetooth version	5.2
Quick start guide	Yes
Surface hardness	6H
Power supply type	External
Ethernet LAN	Yes
Touchscreen	Yes
Number of simultaneous touchpoints	10
Front bezel colour	Black
Certificates
Certification	CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA
