Intel

Intel Wi-Fi 7 BE200 Internal WLAN / Bluetooth 5800 Mbit/s

SKU BE200.NGWG
£28.48
£17.45
£28.48
£17.45
Excluding taxes
Intel WiFi 7 BE200

Description

Orthogonal Frequency-Division Multiple Access (OFDMA)
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-user version of the popular orthogonal frequency-division multiplexing (OFDM) digital modulation scheme. This allows simultaneous low-data-rate transmission from several users.

Specifications

Ports & interfaces
Internal Yes
Interface WLAN / Bluetooth
Host interface M.2
Connectivity technology Wireless
Bandwidth
Maximum data transfer rate 5800 Mbit/s
Wireless LAN features
Wi-Fi band Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Top Wi-Fi standard Wi-Fi 7 (802.11be)
Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Wi-Fi Yes
Antenna
Antenna type 2x2
Technical details
Supported Under vPro Yes
Intel Trusted Execution Technology No
Embedded options available No
Harmonized System (HS) code 8517620090
Export Control Classification Number (ECCN) 5A992C
Commodity Classification Automated Tracking System (CCATS) 740.17B1
Sustainability compliance Yes
Compliance certificates CB, UL
Status Launched
Product brief URL https://www.intel.com/content/www/us/en/secure/content-details/916611/intel-wi-fi-7-be200-5gig-module-commercial-temperature-embedded-module-product-brief.html?DocID=916611
Launch date Q3'23
Network
Wi-Fi band Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Top Wi-Fi standard Wi-Fi 7 (802.11be)
Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Wi-Fi Yes
Security algorithms AES-CCMP, AES-GCMP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3
Bluetooth version 5.4
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11b, IEEE 802.11be, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w
Maximum data transfer rate 5800 Mbit/s
Bluetooth Yes
MU-MIMO Yes
Design
Internal Yes
Antenna type 2x2
Component for PC/Laptop
Software
Windows operating systems supported Windows 10, Windows 11
Linux operating systems supported Yes
System requirements
Windows operating systems supported Windows 10, Windows 11
Linux operating systems supported Yes
Operational conditions
Operating temperature (T-T) 0 - 80 °C
Maximum operating temperature 70 °C
Sustainability
Sustainability compliance Yes
Weight & dimensions
Width 22 mm
Depth 30 mm
Height 2.4 mm
Weight 3.07 g
Security
Security algorithms AES-CCMP, AES-GCMP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3
Performance
Ethernet adapter ARK ID 230078
Security algorithms AES-CCMP, AES-GCMP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3
Windows operating systems supported Windows 10, Windows 11
Linux operating systems supported Yes
Supported Under vPro Yes
Other features
Bluetooth version 5.4
Bluetooth Yes
Ethernet adapter ARK ID 230078
Supported Under vPro Yes
Intel Trusted Execution Technology No
Embedded options available No
Status Launched
Product brief URL https://www.intel.com/content/www/us/en/secure/content-details/916611/intel-wi-fi-7-be200-5gig-module-commercial-temperature-embedded-module-product-brief.html?DocID=916611
Launch date Q3'23
Harmonized System (HS) code 8517620090
Export Control Classification Number (ECCN) 5A992C
Commodity Classification Automated Tracking System (CCATS) 740.17B1
Maximum operating temperature 70 °C
Compliance FIPS
Antenna type 2x2
Logistics data
Harmonized System (HS) code 8517620090
