Intel

Intel Wi-Fi 7 BE201 Internal WLAN / Bluetooth 5000 Mbit/s

SKU BE201.NGWG
£26.98
£16.52
£26.98
£16.52
Excluding taxes
Intel Wi-Fi 7 BE201, 2230, 2x2 BE+BT, vPro

Description

Orthogonal Frequency-Division Multiple Access (OFDMA)
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-user version of the popular orthogonal frequency-division multiplexing (OFDM) digital modulation scheme. This allows simultaneous low-data-rate transmission from several users.

Specifications

Ports & interfaces
Internal Yes
Interface WLAN / Bluetooth
Host interface M.2
Connectivity technology Wireless
Bandwidth
Maximum data transfer rate 5000 Mbit/s
Wireless LAN features
Wi-Fi band Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Top Wi-Fi standard Wi-Fi 7 (802.11be)
Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Wi-Fi Yes
Antenna
Antenna type 2x2
Technical details
Supported Under vPro Yes
Harmonized System (HS) code 8517620090
Export Control Classification Number (ECCN) 5A991B
Compliance certificates CB, UL
Status Launched
Network
Wi-Fi band Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Top Wi-Fi standard Wi-Fi 7 (802.11be)
Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Wi-Fi Yes
Security algorithms 128-bit AES, 256-bit AES, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, WPA2, WPA3
Bluetooth version 5.4
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11b, IEEE 802.11be, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11j, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w
Maximum data transfer rate 5000 Mbit/s
Bluetooth Yes
Design
Internal Yes
Form factor M.2 2230
Antenna type 2x2
Component for PC/Laptop
Software
Windows operating systems supported Windows 10, Windows 11
Linux operating systems supported Yes
System requirements
Windows operating systems supported Windows 10, Windows 11
Linux operating systems supported Yes
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Operating relative humidity (H-H) 50 - 90%
Weight & dimensions
Width 22 mm
Depth 30 mm
Height 2.42 mm
Weight 3.06 g
Security
Security algorithms 128-bit AES, 256-bit AES, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, WPA2, WPA3
Performance
Ethernet adapter ARK ID 230079
Security algorithms 128-bit AES, 256-bit AES, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, WPA2, WPA3
Windows operating systems supported Windows 10, Windows 11
Linux operating systems supported Yes
Supported Under vPro Yes
Other features
Bluetooth version 5.4
Form factor M.2 2230
Bluetooth Yes
Ethernet adapter ARK ID 230079
Supported Under vPro Yes
Status Launched
Harmonized System (HS) code 8517620090
Export Control Classification Number (ECCN) 5A991B
Antenna type 2x2
Logistics data
Harmonized System (HS) code 8517620090
