MSI GT 1030 2GB 2GHD4 LP OC W/LP

NVIDIA GeForce GT 1030, 1189MHz, 2GB GDDR4, 64 bit, 2100MHz, PCI Express x16 3.0, 1 x HDMI, 1 x DP, CUDA, DirectX 12.0, OpenGL 4.5, 20W

Key Features

• 1430 MHz / 1189 MHz
• 2GB DDR4 / 2100 MHz
• Aluminum core for higher stability
• Low profile design saves more spaces
• User can build slim or smaller system
• Large heat sink covers the area of GPU and memory
• Providing the best environment for gaming and multimedia
• Wireless control through mobile devices
• Predator: In-game video recording
• Ensures the best gaming experience by automatically updating users’ game-ready drivers
• Allows users to optimize the game settings to their PC with a single click

Description

STEP UP TO BRILLIANT PC GRAPHICS

Accelerate your entire PC experience with the fast, powerful NVIDIA® GeForce® GT 1030 graphics card. Gaming. HD video and picture editing. The GT 1030's award-winning NVIDIA Pascal™ architecture, powerful graphics engine, and state-of-the-art technologies give you the performance upgrade you need to drive today’s most demanding PC applications.

THE LATEST GAMING TECHNOLOGIES

Pascal is built to meet the demands of next generation displays. It features NVIDIA GameWorks™ technologies for extremely smooth gameplay and cinematic experiences.

PERFORMANCE

Pascal-powered graphics cards give you superior performance and power efficiency, built using ultra-fast FinFET and supporting DirectX™ 12 features to deliver the fastest, smoothest, most power-efficient gaming experiences.

GEFORCE EXPERIENCE

The easiest way to optimize your games and keep your drivers up to date, the GeForce Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you'll be able to update the driver directly, without leaving your desktop.

LOW PROFILE DESIGN

Low profile design saves more spaces and can build slim or smaller system easier.

MILITARY CLASS 4 COMPONENTS

One of the deciding factors in performance is the quality of the components used. That is why MSI only uses MIL-STD-810G certified components for graphics cards. These components have proven durable enough to withstand the torturous circumstances of extreme gaming and overclocking for extended usage.

AFTERBURNER

MSI Afterburner is the world’s most recognized and widely used graphics card overclocking utility which gives you full control of your graphics cards. It also provides an incredibly detailed overview of your hardware and comes with some additional features such as customizing fan profiles, benchmarking and video recording.

Specifications

Processor
FireStream	No
Graphics processor family	NVIDIA
Processor frequency	1189 MHz
Processor boost clock speed	1430 MHz
Parallel processing technology support	Not supported
Maximum displays per videocard	2
CUDA cores	384
CUDA	Yes
Graphics processor	GeForce GT 1030
Memory
Discrete graphics card memory	2 GB
Memory clock speed	2100 MHz
Memory bus	64 bit
Graphics card memory type	GDDR4
Ports & interfaces
HDMI version	2.0b
HDMI ports quantity	1
DisplayPort version	1.4a
VGA (D-Sub) ports quantity	0
DVI-I ports quantity	0
DVI-D ports quantity	0
DisplayPorts quantity	1
Interface type	PCI Express x16 3.0
Video
DirectX version	12.0
OpenGL version	4.5
HDMI version	2.0b
HDCP	Yes
Full HD	Yes
Dual Link DVI	No
CUDA cores	384
PhysX	Yes
Performance
DirectX version	12.0
OpenGL version	4.5
HDCP	Yes
Full HD	Yes
Dual Link DVI	No
TV tuner integrated	No
PhysX	Yes
Design
Cooling type	Passive
Form factor	Half-Height/Half-Length (HH/HL)
Product colour	Black
Number of slots	1
Bracket height	Low-Profile (LP)
Software
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Power
Power consumption (typical)	20 W
Minimum system power supply	300 W
Weight & dimensions
Number of slots	1
Weight	304 g
Height	69 mm
Depth	38 mm
Length	150 mm
Technical details
Cooling type	Passive
Form factor	Half-Height/Half-Length (HH/HL)
Product colour	Black
TV tuner integrated	No
Harmonized System (HS) code	84733020
System requirements
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Minimum system power supply	300 W
Packaging data
Package type	Box
Package weight	544 g
Logistics data
Harmonized System (HS) code	84733020
