StarTech.com Cat5e Patch Cable with Snagless RJ45 Connectors - 1m, Green

StarTech.com 1 m Green Cat5e Snagless RJ45 UTP Patch Cable - 1m Patch Cord - Ethernet Patch Cable - RJ45 Male to Male Cat 5e Cable (45PAT1MGN)

Description

Make Fast Ethernet network connections using this high quality Cat5e Cable, with Power-over-Ethernet capability

The 45PAT1MGN Cat5e patch cable (1m) meets or exceeds all Cat 5e cable specifications to ensure reliable Ethernet network connections, and features a durable green PVC jacket that enables you to color code your network cable runs as needed.

To ensure long-lasting performance, this high quality Cat5e patch cable features a snagless design that protects the RJ45 connector clips from damage and makes the cable less prone to snagging during installation. The cable also features molded PVC strain relief that prevents the RJ45 connector termination points from bending at sharp angles, reducing the risk of cable failure.

Constructed of only top quality materials, this Cat5e patch cord delivers reliable performance and is backed by our lifetime warranty.

100% copper for outstanding value

Get the highest value for your cable investment with our Cat 5e cables, each one manufactured using high-quality copper conductors.

24-gauge wire for high-performance network connection

Ensure high-performance capability for your demanding Ethernet applications, such as Power-over-Ethernet, using cables that include 24 AWG copper.

50-micron gold connectors provide peak conductivity

Rely on our RJ45 connectors to deliver optimum conductivity while eliminating signal loss due to oxidation or corrosion.

The StarTech.com Advantage

Specifications

Technical details
Product colour	Green
Cable standard	Cat5e
Cable shielding	U/UTP (UTP)
Connector 1	RJ-45
Connector 2	RJ-45
Connector contacts plating	Gold
Jacket material	Polyvinyl chloride (PVC)
Conductor type	Stranded
Cable length	1 m
Cable rating	CMG (CM)
Compliance certificates	RoHS
Features
Product colour	Green
Cable rating	CMG (CM)
Snagless cable boot	Yes
Frequency	350 MHz
AWG wire size	24
Cable standard	Cat5e
Cable shielding	U/UTP (UTP)
Connector 1	RJ-45
Connector 2	RJ-45
Connector contacts plating	Gold
Jacket material	Polyvinyl chloride (PVC)
Conductor type	Stranded
Cable length	1 m
Harmonized System (HS) code	84733080
Connector 2 gender	Male
Connector 1 gender	Male
Weight & dimensions
Weight	40 g
Packaging data
Package width	200 mm
Package depth	220 mm
Package height	12 mm
Package weight	49 g
Quantity per pack	1 pc(s)
Logistics data
Products per master (outer) case	250 pc(s)
Master (outer) case width	100 mm
Master (outer) case length	100 mm
Master (outer) case height	230 mm
Harmonized System (HS) code	84733080
