StarTech.com Cisco GLC-SX-MM Compatible SFP Transceiver Module - 1000BASE-SX~Cisco GLC-SX-MM Compatible SFP Module - 1000BASE-SX - 1GbE Multimode Fiber MMF Optic Transceiver - 1GE Gigabit Ethernet SFP - LC 550m - 850nm - Cisco IE3400, IE3300, IE3200

StarTech.com Cisco GLC-SX-MM Compatible SFP Module - 1000BASE-SX - 1GbE Multimode Fiber MMF Optic Transceiver - 1GE Gigabit Ethernet SFP - LC 550m - 850nm - Cisco IE3400, IE3300, IE3200 (SFPGLCSXMMST)

Key Features

• 100% CISCO GLC-SX-MM COMPATIBLE: Works with Cisco switches like IE3400, IE3300, IE3200, ME1200, ME2400 and others
• TECHNICAL SPECS: 1000BASE-SX / 1 Gbps / Multi Mode (MMF) / LC Connector / 850nm / Distances up to 550m (1804ft)
• TESTED FOR OEM HOST COMPATIBILITY: Hot-swappable in Cisco routers and switches
• WORKS WITH MSA COMPLIANT SWITCHES: Also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules
• THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance.

Description

1000 Mbps (1 Gbps) | Multi Mode Fiber | LC | 550 m (1804 ft) | Lifetime Warranty

The SFPGLCSXMMST is a Cisco GLC-SX-MM compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco® brand switches and routers. It delivers dependable 1GbE (1000 Mbps) connectivity over fiber cable, for 1000BASE-SX compliant networks, with a maximum distance of up to 550 m (1804 ft).

Technical Specifications:

• Wavelength: 850 nm
• Maximum Data Transfer Rate: 1.25 Gbps
• Type: Multi Mode Fiber
• Connection Type: LC Connector
• Maximum Transfer Distance: 550 m (1804 ft)
• MTBF: 3,381,761 hours
• Power Consumption: Less than 1 Watt
• Digital Diagnostics Monitoring (DDM): No

This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

The StarTech.com Advantage

Specifications

Performance
SFP transceiver type	Fiber optic
Wavelength-division multiplexing (WDM)	No
Digital Diagnostics Monitoring (DDM)	No
Fiber optic connector	LC
Networking standards	IEEE 802.3z
Maximum transfer distance	550 m
Wavelength	850 nm
Duplex system	Full, Half
Maximum data transfer rate	1250 Mbit/s
Interface type	SFP
Multi-mode fiber (MMF) supported	Yes
SFP transceiver standard	SX
Product colour	Silver
Hot-swap	Yes
Compatible products	GLC-SX-MM
Mean time between failures (MTBF)	3381761 h
Brand compatibility	Cisco
Harmonized System (HS) code	85369010
Features
Product colour	Silver
Hot-swap	Yes
Compatible products	GLC-SX-MM
Mean time between failures (MTBF)	3381761 h
Brand compatibility	Cisco
Certification	CE, FCC, UL, REACH
Power
Power consumption (typical)	1 W
Certificates
Certification	CE, FCC, UL, REACH
Compliance certificates	RoHS
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	30 - 70%
Network
SFP transceiver type	Fiber optic
Fiber optic connector	LC
Networking standards	IEEE 802.3z
Maximum data transfer rate	1250 Mbit/s
Interface type	SFP
Weight & dimensions
Width	12 mm
Depth	60 mm
Height	10 mm
Weight	16 g
Package depth	118 mm
Package width	95 mm
Package height	32 mm
Package weight	95 g
Packaging content
Quantity per pack	1 pc(s)
Technical details
Package width	95 mm
Package height	32 mm
Hot-swap	Yes
Maximum transfer distance	550 m
Wavelength	850 nm
Duplex system	Full, Half
Compatible products	GLC-SX-MM
Compliance certificates	RoHS
Packaging data
Package depth	118 mm
Package width	95 mm
Package height	32 mm
Package weight	95 g
Logistics data
Quantity per pack	1 pc(s)
Master (outer) case width	260 mm
Master (outer) case length	305 mm
Master (outer) case height	205 mm
Products per master (outer) case	36 pc(s)
Harmonized System (HS) code	85369010
