StarTech.com Dell EMC SFP-1G-SX Compatible SFP Module - 1000BASE-SX - 1GbE Multimode Fiber MMF Optic Transceiver - 1GE Gigabit Ethernet SFP - LC 550m - 850nm - DDM

StarTech.com Dell EMC SFP-1G-SX Compatible SFP Module - 1000BASE-SX - 1GbE Multimode Fiber MMF Optic Transceiver - 1GE Gigabit Ethernet SFP - LC 550m - 850nm - DDM (SFP1GSXEMCST)

Key Features

• 100% DELL EMC SFP-1G-SX COMPATIBLE SFP TRANSCEIVER: Designed, programmed and tested to work with compatible Dell EMC switches and routers to deliver reliable 1GbE connectivity
• TECHNICAL SPECS: 1000BASE-SX / 1Gbps / Multi Mode (MMF) / LC Connector / 850nm / Digital Diagnostic Monitoring (DDM) / Distances up to 550m (1804ft)
• TESTED FOR OEM HOST COMPATIBILITY: Hot-swappable in Dell EMC routers and switches; DDM support reports the transceiver's status to most SNMP network management tools
• WORKS WITH MSA COMPLIANT SWITCHES: Also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules
• THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance.

Description

1000 Mbps (1 Gbps) | Multi Mode Fiber | LC | 550 m (1804 ft) | Lifetime Warranty

The SFP1GSXEMCST is a Dell EMC SFP-1G-SX compatible fiber transceiver module that has been designed, programmed and tested to work with Dell EMC brand switches and routers. It delivers dependable 1 GbE connectivity over fiber cable, for 1000BASE-SX compliant networks, with a maximum distance of up to 500 m (1640 ft)).

Technical Specifications:

• Wavelength: 850nm
• Maximum Data Transfer Rate: 1000 Mbps (1 Gbps)
• Type: Multi Mode
• Connection Type: LC Connector
• Maximum Transfer Distance: 550 m (1804 ft)
• MTBF: 53,972,659 hours
• Power Consumption: Low power consumption
• Digital Diagnostics Monitoring (DDM): Yes

This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

The StarTech.com Advantage

Specifications

Performance
SFP transceiver type	Fiber optic
Digital Diagnostics Monitoring (DDM)	Yes
Fiber optic connector	LC
Maximum transfer distance	550 m
Wavelength	850 nm
Duplex system	Full
Maximum data transfer rate	1000 Mbit/s
Interface type	SFP
Multi-mode fiber (MMF) supported	Yes
SFP transceiver standard	SX
Fiber ethernet cabling technology	1000BASE
Country of origin	China
Product colour	Silver
Hot-swap	Yes
Compatible products	SFP-1G-SX
Mean time between failures (MTBF)	53972659 h
Brand compatibility	Dell
Harmonized System (HS) code	85369010
Features
Product colour	Silver
Hot-swap	Yes
Compatible products	SFP-1G-SX
Mean time between failures (MTBF)	53972659 h
Brand compatibility	Dell
Country of origin	China
Certification	CE, FCC, UL, REACH
Certificates
Certification	CE, FCC, UL, REACH
Compliance certificates	RoHS
Network
SFP transceiver type	Fiber optic
Fiber optic connector	LC
Maximum data transfer rate	1000 Mbit/s
Interface type	SFP
Weight & dimensions
Width	58.4 mm
Depth	13.9 mm
Height	12.6 mm
Weight	30 g
Package depth	115 mm
Package width	90 mm
Package height	31 mm
Package weight	50 g
Packaging content
Quantity per pack	1 pc(s)
Technical details
Package width	90 mm
Package height	31 mm
Hot-swap	Yes
Maximum transfer distance	550 m
Wavelength	850 nm
Duplex system	Full
Compatible products	SFP-1G-SX
Compliance certificates	RoHS
Packaging data
Package depth	115 mm
Package width	90 mm
Package height	31 mm
Package weight	50 g
Logistics data
Quantity per pack	1 pc(s)
Country of origin	China
Master (outer) case width	90 mm
Master (outer) case length	115 mm
Master (outer) case height	31 mm
Products per master (outer) case	1 pc(s)
Harmonized System (HS) code	85369010
