The TP-Link Omada EAP670 is a dual-band Wi-Fi 6 access point for businesses and organisations that need to serve many users across an office, meeting room, hospitality venue or education space. Its ceiling or wall mounting options help position wireless coverage where people use it.
Simultaneous 574 Mbps on 2.4 GHz and 4804 Mbps on 5 GHz totals 5378 Mbps WiFi speeds.
Specification
| Specification | Detail |
|---|---|
| High-Efficiency WiFi 6 | More connected devices can enjoy faster speeds. |
| Centralized Cloud Management | Omada SDN integration manages the whole network locally or from the cloud via web UI or Omada app. |
| 160 MHz Channel | Double the data at peak transmission times on a single stream with HE160. |
| Seamless Roaming | Video streams and voice calls are unaffected as users move between locations. |
| Omada Mesh | Enables wireless connectivity between access points for extended range and flexible deployment. |
| PoE+ Powered | Supports both 802.3at PoE+ and DC (adapter included) power supply for flexible installations. |
| Interface | 1x 2.5 Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE) |
| Button | Reset |
| Power Supply | 802.3at PoE 12 V / 1.5 A DC |
| Power Consumption | EU: 18.1 W |
| Dimensions ( W x D x H ) | 9.6 x 9.6 x 2.5 in (243 x 243 x 64 mm) |
| Antenna Type | Internal Omni 2.4 GHz: 2x 4 dBi 5 GHz: 4x 5 dBi |
| Mounting | Ceiling /Wall Mounting (Kits included) |
| Wireless Client Capacity | 250+ |
| Wireless Standards | IEEE 802.11ax/ac/n/g/b/a |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | 5 GHz: Up to 4804 Mbps 2.4 GHz: Up to 574 Mbps |
| Wireless Functions | 1024-QAM 4x Longer OFDM Symbol OFDMA Multiple SSIDs (Up to 16 SSIDs, 8 for each band) Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control (Adjust Transmit Power on dBm) QoS(WMM) MU-MIMO HE160 (160 MHz Bandwidth) Seamless Roaming Omada Mesh Band Steering Load Balance Airtime Fairness Beamforming Rate Limit Reboot Schedule Wireless Schedule Wireless Statistics based on SSID/AP/Client |
| Wireless Security | Captive Portal Authentication Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients SSID to VLAN Mapping Rogue AP Detection 802.1X Support WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Transmission Power | CE: <20 dBm(2.4 GHz, EIRP) <23 dBm(5 GHz, , band1 & band2, EIRP) <30 dBm(5 GHz, , band3, EIRP) FCC: <25 dBm (2.4 GHz) <28 dBm (5 GHz) |
| Omada App | Yes |
| Centralized Management | Omada Hardware Controller (OC300) Omada Hardware Controller (OC200) Omada Software Controller Omada Cloud-Based Controller |
| Cloud Access | Yes (Through OC300, OC200, Omada Software Controller, or Omada Cloud-Based Controller) |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| System Logging | Local/Remote Syslog |
| SSH | Yes |
| Web-based Management | HTTP/HTTPS |
| L3 Management | Yes |
| Multi-site Management | Yes |
| Management VLAN | Yes |
| Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller. |
| Certification | CE, FCC, RoHS |
| Package Contents | EAP670 Power Adapter Ceiling/Wall Mounting Kits Installation Guide |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux |
-
