The TP-Link TL-WA1201 is an AC1200 wireless access point for homes, studios and small offices that need to add Wi-Fi to an existing wired network. It also suits small businesses that want to offer a separate guest network.
Fast Wi-Fi 5 speed in both 5 GHz and 2.4 GHz.
Advanced Features
- Captive Portal
Specification
| Specification | Detail |
|---|---|
| Flexible Deployment | Supports Passive PoE to carry electrical power and data simultaneously. |
| Multiple Modes | Supports Access Point, Range Extender, Multi-SSID, and Client modes to meet any network needs. |
| MU-MIMO Technology | Simultaneously transfers data to multiple devices for 2x faster performance. |
| Boosted Coverage | Four fixed antennas equipped with Beamforming technology extend and concentrate the Wi-Fi signals. |
| Captive Portal | Offers a designed portal page for heightened security and marketing. |
| Lightning-Fast AC1200 Dual Band Wi-Fi | Upgrade your home or office network with the advanced 802.11ac Wave 2 AP, which offers dual-band speeds of up to AC1200—three times the performance of Wireless N. MU-MIMO technology enables the AP to serve multiple devices simultaneously without congestion or latency. All devices get their data faster and Wi-Fi is used more efficiently! |
| Gigabit-Class Wired Performance | The gigabit Ethernet port makes full use of gigabit-class bandwidth provided by a local ISP to ensure reliable network connections. It also provides an ultra-fast connection for wired devices such as PCs, IPTVs, and game consoles, etc. |
| Deploy Anywhere with Just One Cable | Power over Ethernet (PoE) allows your Ethernet cable to carry electrical power and data simultaneously, making deployment effortless and flexible. An elegant appearance and simple mounting design make it easy to attach the Access Point to any wall or desktop, blending in perfectly with most interior decoration. |
| Boosted Wi-Fi Coverage | Four external antennas equipped with Beamforming technology concentrate Wi-Fi signals towards your devices to extend reliable Wi-Fi to every corner of your home or office—even over long distances. |
| Captive Portal Marketing | Captive Portal provides a secure guest network and offers unique marketing opportunities, especially for small businesses like cafes or salons. Utilize a flexibly designed portal page—requiring customers to view an advertisement or accept a set of terms for internet access—to improve brand awareness or deliver marketing messages. |
| Multi-Mode 4 in 1 | Multiple operation modes are supported to give you full flexibility to tailor the Access Point to fit your network's needs. |
| Interface | 1x 10/100/1000 Mbps Ethernet Port (Supports Passive PoE) |
| Button | Power On/Off Button, WPS Button, Reset Button |
| Wireless Standards | IEEE802.11b/g/n 2.4 GHz, IEEE 802.11ac/n/a 5 GHz |
| Dimensions (W x D x H) | 8.9 x 5.7 x 1.5 in (225 x 145.5 x 37 mm) |
| Antenna | 4 Fixed High Performance Antennas |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | 867 Mbps at 5 GHz, 300 Mbps at 2.4 GHz |
| Reception Sensitivity | 5 GHz: 11a 6 Mbps: -95 dBm, 11a 54 Mbps: -81 dBm 11ac VHT20(MCS0): -94 dBm, 11ac VHT20(MCS8): -71 dBm 11n HT40(MCS0): -91 dBm, 11n HT40(MCS7): -71 dBm 11ac VHT80(MCS0): -88 dBm, 11ac VHT80(MCS9): -63 dBm 2.4 GHz: 11g 54Mbps: -78 dBm 11n HT20(MCS0): -92 dBm, 11n HT20(MCS7): -74 dBm 11n HT40(MCS0): -88 dBm, 11n HT40(MCS7): -72 dBm |
| Wireless Modes | Access Point, Range Extender, Client, Multi-SSID |
| Wireless Functions | Enable/Disable Wireless Radio, WMM, Wireless Statistics, DHCP Server, Access Control |
| Wireless Security | WPA3, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions |
| DHCP | Server, DHCP Client List |
| Quality of Service | WMM |
| Transmission Power | CE: <20dBm(2.4GHz), <23dBm(5.15GHz~5.25GHz) FCC: <30dBm(2.4GHz&5GHz) |
| Network Services Enabled by Default | Web Server Manage and configure device through web (HTTP/HTTPS) Port: 80/443 Protocol: TCP DHCP Server IP address assignment (DHCP) Port: 67 Protocol: UDP App management Manage and configure device through app Port: 20002 Protocol: UDP |
| Certification | CE, FCC, RoHS |
| Protocol Support | IPv4, IPv6 |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser |
| Package Content | Wireless Access Point TL-WA1201 Power Adapter RJ45 Ethernet Cable Quick Installation Guide PoE Power Injector |
-
