TP-LINK

TP-Link TL-WA1201 wireless access point 867 Mbit/s White Power over Ethernet (PoE)

SKU TL-WA1201
£35.01
£35.01
Excluding taxes
AC1200 Wireless Access Point, AC1200 Dual-Band Wi-Fi, Multiple Modes,

Key Features

  • AC1200 Dual-Band Wi-Fi – Fast Wi-Fi 5 speed in both 5 GHz and 2.4 GHz
  • Flexible Deployment – Supports Passive PoE to carry electrical power and data simultaneously
  • Multiple Modes – Supports Access Point, Range Extender, Multi-SSID, and Client modes to meet any network needs
  • MU-MIMO Technology – Simultaneously transfers data to multiple devices for 2× faster performance
  • Boosted Coverage – Four fixed antennas equipped with Beamforming technology extend and concentrate the Wi-Fi signals
  • Captive Portal – Offers a designed portal page for heightened security and marketing

Description

867Mb 802.11bgn MU-MIMO WIRELESS LAN PoE ACCESS POINTComplies with 2.4GHz Draft 802.11bgn and backward compatible with IEEE 802.11g,b standards, Up to 867Mbps, Supports Access Point, Client, Universal WDS Repeater and Wireless Bridge Modes, Setup WPA Security at the push of a QSS button, Advanced MU-MIMO Technology with 4 FIxed Antennas, Supports PoE up to 30 Mtrs, Supports advanced MU-MIMO technology enhancing the throughput and coverage range Significantly, CCA improves performance and avoids channel conflicts, Up to 4 SSIDs and VLAN support, Supplied with PoE Adaptor

Specifications

Data transmission
Ethernet LAN data rates 10,100,1000 Mbit/s
Maximum data transfer rate 867 Mbit/s
Performance
2.4 GHz Yes
5 GHz Yes
Wi-Fi Multimedia (WMM)/(WME) Yes
Auto Wireless Distribution System (WDS) Yes
On/off switch Yes
Reset button Yes
Universal Plug and Play (UPnP) Yes
VLAN support Yes
Quality of Service (QoS) support Yes
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates 10,100,1000 Mbit/s
Maximum data transfer rate 867 Mbit/s
MIMO type Multi User MIMO
MIMO Yes
Compatible operating systems Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Network
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Management features
Universal Plug and Play (UPnP) Yes
VLAN support Yes
Quality of Service (QoS) support Yes
Features
6 GHz No
2.4 GHz Yes
5 GHz Yes
Wi-Fi Multimedia (WMM)/(WME) Yes
VLAN support Yes
Quality of Service (QoS) support Yes
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates 10,100,1000 Mbit/s
Maximum data transfer rate 867 Mbit/s
Transmitting power (FCC) 30 dBm
Transmitting power (CE) 20 - 23 dBm
MIMO type Multi User MIMO
MIMO Yes
Maximum data transfer rate (2.4 GHz) 300 Mbit/s
Maximum data transfer rate (5 GHz) 867 Mbit/s
Virtual LAN features Multicast VLAN
Compatible operating systems Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Security
Auto Wireless Distribution System (WDS) Yes
Security algorithms 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Access Control List (ACL) Yes
Service Set Identifier (SSID) features Multiple SSIDs
Protocols
Universal Plug and Play (UPnP) Yes
DHCP server Yes
DHCP client Yes
IPv4 & IPv6 features Dual stack IPv4/IPv6
Ports & interfaces
USB 2.0 ports quantity 0
Ethernet LAN (RJ-45) ports 1
Power
Output voltage 12 V
Output current 1.5 A
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) type supported Active PoE
Design
Placement Table
On/off switch Yes
Product colour White
Reset button Yes
WPS push button Yes
Antenna
Antenna type External
Antennas quantity 4
Technical details
Reset button Yes
WPS push button Yes
Sustainability compliance Yes
Compliance certificates RoHS, Federal Communications Commission (FCC), CE
Certificates
Compliance certificates RoHS, Federal Communications Commission (FCC), CE
Software
Access Control List (ACL) Yes
Weight & dimensions
Width 225 mm
Depth 145.5 mm
Height 37 mm
Package width 400 mm
Package depth 255 mm
Package height 69 mm
Package weight 860 g
Packaging data
Quick start guide Yes
PoE adapter included Yes
Package width 400 mm
Package depth 255 mm
Package height 69 mm
Package weight 860 g
Cables included LAN (RJ-45)
AC adapter included Yes
Packaging content
Quick start guide Yes
PoE adapter included Yes
Cables included LAN (RJ-45)
AC adapter included Yes
Quantity per pack 1 pc(s)
Operational conditions
Operating relative humidity (H-H) 10 - 90%
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 10 - 90%
System requirements
Compatible operating systems Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Sustainability
Sustainability compliance Yes
Other features
WPS push button Yes
Logistics data
Quantity per pack 1 pc(s)
