TP-LINK

TP-Link VIGI 64 Channel Network Video Recorder

SKU VIGI NVR4064H
£795.03
£795.03
Excluding taxes
VIGI 64 Channel Network Video Recorder

Key Features

  • 64-Channel Live View and 4K HDMI Video Output
  • Up to 16-ch @ 2MP (25fps) / 8-ch @ 4MP (30fps) Decoding Capability
  • 16-Channel Synchronous Playback
  • 320 Mbps Incoming Bandwidth and 320 Mbps Outgoing Bandwidth
  • 4× SATA Interfaces and 1 Up to 16 TB
  • H.265+ Compression Technology
  • HDMI and VGA Simultaneous Output
  • Remote Monitoring

Description

Security Never Shuts Down
64 Channel Network Video

Feature-Packed Ports for SMB Surveillance

Dual Ethernet Ports Design

Multi-Address Mode
Allows for the implementation of two different gateways

Network Fault-Tolerance
Creates a safeguard or redundancy for your data

Port Aggregation
Realizes bandwidth stack and mutual backup

One-Click System Initialize
VIGI NVRs enable quick camera additions, HDD initialization, and storage scheduling with a single click, reducing setup expenses.

Specifications

Performance
Video input channels 64 channels
Alarm input channels 16
Alarm output channels 4
Maximum resolution 3840 x 2160 pixels
Video formats supported H.264, H.264+, H.265, H.265+
Supported network protocols UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP
Backup function Yes
Audio formats supported G.711 A-law, G.711 μ-law, G.726
Playback modes Digital zoom, Fast play, Forward, Full screen, Pause, Play, Stop
Ethernet LAN data rates 10,100,1000 Mbit/s
Recording modes Manual, Schedule
Audio system 2-way
Supported resolutions 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
Video motion detection Yes
Video loss detection Yes
Number of simultaneously playbacked channels 16 channels
Video recording modes 720p, 1080p
Output bandwidth 320 Mbit/s
Input bandwidth 320 Mbit/s
Hard drive
Number of HDDs supported 4
Maximum storage capacity 64 TB
HDD interface SATA
Number of HDDs installed 0
HDD capacity 0 GB
Storage
Number of HDDs supported 4
Maximum storage capacity 64 TB
HDD interface SATA
Number of HDDs installed 0
HDD capacity 0 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports 2
VGA (D-Sub) output ports 1
USB 2.0 ports quantity 2
Supported network protocols UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP
eSATA Yes
Audio RCA inputs 1
Ethernet LAN data rates 10,100,1000 Mbit/s
Audio RCA outputs 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 1
eSATA ports quantity 1
RS-232 ports 1
HDMI ports quantity 2
Storage relative humidity (H-H) 10 - 90%
Features
Rack mounting Yes
Reset button Yes
Buzzer off Yes
Product colour Black
Power
Output current 1.5 A
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
Power consumption (max) 48.38 W
System requirements
Mobile operating systems supported Android, iOS
Browser supported Chrome (57+), Firefox (52+), Edge (91+)
Operational conditions
Operating temperature (T-T) -10 - 55 °C
Operating relative humidity (H-H) 10 - 90%
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 10 - 90%
Technical details
Compliance certificates BSMI, CE, Federal Communications Commission (FCC), KC, UKCA, VCCI
Weight & dimensions
Width 440 mm
Depth 330 mm
Height 44 mm
Weight 4 kg
Package width 440 mm
Package depth 528 mm
Package height 100 mm
Package weight 5 kg
Packaging content
Packaging content - Mouse - Installation Guide - Power Cord - HDD Power Cables - HDD Data Cables - Terminal Blocks - Mounting Brackets - Screws - Rubber Feet
