The Ubiquiti Gateway Max is a compact independent gateway for small to medium sites. It suits small businesses and advanced home users who want to manage a UniFi network with dedicated routing and security hardware.
Compact, multi-WAN independent gateway with full 2.5G support for high-performance networking at small-to-medium sites.
Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server
Up to 1.5 Gbps routing with IDS/IPS
(1) 2.5 GbE WAN port
(4) 2.5 GbE LAN ports, including (1) remappable to WAN
USB-C powered
Managed with UniFi Network 8.1.113 and later
Specification
| Specification | Detail |
|---|---|
| Performance | WiFi QoS with UniFi APs Application, domain, and country-based QoS Application and device type identification Internet quality and outage reporting |
| Next-Generation Security | Application-aware firewall rules Signature-based IPS/IDS threat detection Content, country, domain, and ad filtering VLAN/subnet-based traffic segmentation Full stateful firewall |
| Advanced Networking | License-free SD-WAN WireGuard, L2TP and OpenVPN server OpenVPN client OpenVPN and IPsec site-to-site VPN One-click Teleport and Identity Enterprise VPN Policy-based WAN and VPN routing DHCP relay Customizable DHCP server IPv6 ISP support |
| Dimensions | 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2") |
| Weight | 520 g (1.1 lb) |
| Enclosure Material | Polycarbonate |
| Resistance | IK04 |
| Processor | Quad-core ARM Cortex-A53 at 1.5 GHz |
| Memory Information | 2GB DDR4 |
| Management Interface | Ethernet Bluetooth |
| Networking Interface | LAN: (4) 2.5 GbE RJ45 ports WAN: (1) 2.5 GbE RJ45 port |
| IDS/IPS Throughput | 1.5 Gbps* *Measured with iPerf3 on DHCP WAN. Performance may be reduced with PPPoE depending on ISP implementation. |
| Power Method | USB type C (5V/3A) |
| Supported Voltage Range | 100–240V |
| Maximum Power Consumption | 9.6W |
| LED | Ethernet White: link/activity |
| Button | (1) Factory reset |
| Ambient Operating Temperature | -10 to 40° C (14 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
-
