Ubiquiti

Ubiquiti U-POE PoE adapter Gigabit Ethernet 48 V

SKU U-POE
£8.00
£6.00
£8.00
£6.00
Excluding taxes
RJ45, 200mV p-p, 15W, 500mA, 86 x 46 x 33 mm

Key Features

  • Delivers up to 15W of PoE
  • Surge, peak pulse, and overcurrent protection
  • Contains RJ45 data input, AC cable with earth ground, and PoE output
  • LED indicator for status monitoring

Description

An adapter that can power UniFi PoE devices, reduce dependency on PoE switch power, and provide a Gigabit LAN connection.

Specifications

Network
Power over Ethernet (PoE) Yes
Ethernet interface type Gigabit Ethernet
Power over Ethernet (PoE) type supported Active PoE
Power over Ethernet (PoE) voltage 48 V
Features
Easy to install Yes
Surge protection Yes
Product colour White
LED indicators Status
Ports & interfaces
RJ-45 input ports 2
Power
Output power 15 W
Power over Ethernet (PoE) voltage 48 V
Input current 0.5 A
AC adapter input voltage 100 - 240 V
AC adapter frequency 50/60 Hz
Inrush current 100 A
Efficiency 84.25%
Switching frequency 65 kHz
Line regulation 3%
Load regulation 5%
Response time 1 ns
Certificates
Compliance certificates CE, UL
Operational conditions
Storage temperature (T-T) -30 - 70 °C
Operating temperature (T-T) -30 - 70 °F
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 10 - 95%
Weight & dimensions
Weight 100 g
Width 86 mm
Depth 46 mm
Height 33 mm
Technical details
Power over Ethernet (PoE) Yes
Operating temperature (T-T) -30 - 70 °F
Input current 0.5 A
Ethernet interface type Gigabit Ethernet
Compliance certificates CE, UL
Indication
LED indicators Status
