The Ubiquiti UniFi Switch Flex Mini 3-pack is a set of compact managed switches for home offices, small workspaces and other setups that need more wired network connections. Each switch provides five Gigabit Ethernet ports, so you can connect computers, printers, televisions and other network devices over Ethernet.

5-Port managed Gigabit Ethernet switch powered by 802.3af/at PoE or 5V, 1A USB-C power adapter

Build and expand your network with the UniFi Switch, part of the Ubiquiti Networks UniFi Enterprise System. The UniFi Switch, model USW-Flex-Mini, is a smart managed Gigabit switch. It offers 5 RJ45 Ethernet ports, providing 1 Gigabit links to your devices. Power up the USW-Flex-Mini with the included USB Type-C power adapter or with 802.3af PoE Ethernet in port 1.

Specification

Specification Detail
Works with UniFi Network Controller Manage Your Networks from a Single Control Plane
Intuitive and Robust Configuration, Control and Monitoring
Remote Firmware Upgrade
Users and Guests
Guest Portal/Hotspot Support
Dimensions 107.16 x 70.15 x 21.17 mm
(4.22 x 2.76 x 0.83")
Weight 150 g
(5.29 oz)
Networking Interfaces (5) 10/100/1000 Mbps RJ45 Ports
PoE In Interface 802.3af/at PoE (Pins 1, 2+; 3, 6-)
Max Power Consumption 2.5W
Power Method USB Type C, 5V
802.3af/at PoE (44 - 57VDC, 0.05 - 0.04A)
Power Supply Not Included - USB C
Voltage Range USB Type C - 4.7 - 5.2VDC
802.3af/at PoE - 44 - 57VDC
LEDs System - Status
RJ45 Data Ports - Link/Speed/Activity
ESD/EMP Protection ± 16kV Air, ± 12kV Contact
Operating Temperature -5 to 45C (23 to 113F)
Operating Humidity 10 to 90% Noncondensing
Certifications CE, FCC, IC
